Manych-Class (Project 1549 Class) Russian Water Supply Transport Vessel
Manych-Class
Water Supply Transport Vessel
Other
Basic Information
Name
Manych-Class (Project 1549 Class) Russian Water Supply Transport Vessel
Designation
Manych-Class
Alternate Designation
Manych-Class; Project 1549 Class
Equipment Type
Water Supply Transport Vessel
Manufacturer
Karamaki Zavod
Date of Introduction
1972
Description
Manych-Class (Project 1549 Class) Russian Water Supply Transport Vessel provides potable water to submarines and surface ships for crew consumption; they also provide water for surface ships for use in boilers. The Manych was refitted in Bulgaria during the mid-1990s.
Naval & Littoral Specifications
Crew
65
Beam
15.80 m
Draft
5.70 m
Variants
Manych
Commissioned: 1972
Status: Active
Fleet: Black Sea Fleet
Tagil
Commissioned: 1976
Status: Decommossioned in 2007
Fleet: Pacific Fleet
System
Alternative Designation
Manych-Class; Project 1549 Class
Type
Water Supply Transport Vessel
Builder
Karamaki Zavod, Vyborg, Finland
Crew
65 ea
Cargo Capacity
1,800 tons of potable or boiler water, 20 tons distilled water and 180 tons of provisions.
Dimensions
Length
115.80 m
Beam
15.80 m
Draft
5.70 m
Displacement, Standard
3,065 tons
Displacement, Full Load
5,700 tons
Propulsion System
Engine Name
2 Type 58A
Engine Type
Diesel
Engine Power
9,000 total bhp
Range
11,500 nm at 12 knots; 7,500 nm at l6 knots
Maximum Speed
18 knots
Gun Weapon Systems
Note
In the 1981 the 2 x twin 57-mm (AK-725).
Radar
Navigation Radar
2 x Volga (Don-Kay) navigation radar.
Protection
Hull
INA
Countermeasures
INA
NBC Water Washdown System
Yes
Details
Country of Origin
Russia
Category
Support Ships
Naval > Support Ships
Filter Label
M
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
115.8 m
Width
15.8 m
Height
—
Weight
5700000 kg
Operators (1)
Russia
