Hermes 450

Hermes 450

Tactical Unmanned Air Vehicles
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Hermes 450
Designation
Hermes 450
Alternate Designation
H-450, Kochav 450, Watchkeeper (UK MoD contract), Watchkeeper X, Watchkeeper XR, WK450
Equipment Type
Tactical Unmanned Air Vehicles
Manufacturer
Elbit Systems
Date of Introduction
1998
Description

The Hermes 450 is a tactical long endurance air surveillance and target acquisition Unmanned Aerial Vehicle (UAV). Hermes 450 is a member of Hermes family of unmanned aerial systems. It provides real-time electro-optic and electronic battlefield intelligence data. Enhanced and fully redundant avionics have been provided to this aircraft as well as fully autonomous flight patter with in-flight redirection. The Watchkeeper is a long endurance airborne surveillance system designed to operate in all weather conditions by day and by night. It is based upon Hermes UAV family and will deliver both radar and optical high-resolution imagery to UK commanders. Elbit Systems' Hermes 450, designated WK450 for the Watchkeeper program, can stay on station for more than 16 hours. Moreover, Watchkeeper program will contribute to Network Enabled Capability through a fleet of WK450 UAVs equipped with day/night sensors and laser designators connected via data link to a network of Ground Control Stations . The UK MoD gave green light to the project in July 2005 with a planned entry into service date for 2010. The entire program has been valued at £700 million. As of 2022, the program value is £1.2 billion.

Air & Air Defense Specifications
Max Speed 175.0 km/h
Range 200.0 km
Service Ceiling 6100 m
Wingspan 10.50 m
Overview (Deagel)
Group Tactical Unmanned Air Vehicles
Status Active
Also Known As H-450, Kochav 450, Watchkeeper (UK MoD contract), Watchkeeper X, Watchkeeper XR, WK450
Origin Israel
Contractor Elbit Systems
Initial Operational Capability (IOC) 1998
Total Production ?
Unitary Cost USD $60 million
Specifications (Deagel)
Crew 0
Dimensions — Length 6.1 meter
Dimensions — Wingspan 10.5 meter
Mass — Max Takeoff Weight 450 kilogram
Mass — Payload 150 kilogram
Performance — Ceiling 6,100 meter
Performance — Max Range 200 kilometer
Power — Max Power at TakeOff 52 shp
Speed — Top Speed at High Altitude 175 kph
Time — Flight Endurance 20 hour
Gear (Deagel)
Item 1 Loitering Weapons: Fire Shadow
Item 2 Radar Systems: Gabbiano (1)
Variants
Variant 1 Hermes 450
Variant 2 Hermes 180
Variant 3 Hermes 900
Variant 4 Hermes 650 Spark
Details
Country of Origin Israel
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
6.1 m
Width
10.5 m
Height
Weight
450 kg
Operators (14)
United Kingdom
Israel
Brazil
Azerbaijan
Botswana
Colombia
Georgia
Mexico
North Macedonia
Philippines
Romania
Singapore
Thailand
Zambia
