Piranha 3+

Piranha 3+

Wheeled Armored Vehicles
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Piranha 3+
Designation
Piranha 3+
Alternate Designation
Equipment Type
Wheeled Armored Vehicles
Manufacturer
General Dynamics European Land Systems
Date of Introduction
2014
Description

The General Dynamics European Land Systems (GDELS) Piranha 3+ is an improved version of the Piranha III 8x8 with a gross vehicle weight of 27 tons and enhanced level of protection, off-road mobility and growth potential. The Piranha 3+ armored personnel carrier (APC) has a crew of three-man (driver, gunner and commander) and can transport up to 9 fully-equipped infantrymen. Besides the vehicle features a roof-mounted Kongsberg 12.7mm Protector remote weapon station, a modular protection system, larger internal volume and a 10 percent payload increase. A new engine provides up to 30% more power (520-hp), a top speed of 110 kilometers per hour and a maximum range of 1,000 kilometers. Optionally the Piranha 3+ can be equipped with an amphibious drive to operate as a marine infantry vehicle. The Piranha 3+ was unveiled in June 2014 at the Eurosatory exhibition, Paris, France.

Ground Specifications
Crew 3
Troop Capacity 9
Mobility Type Wheeled (8x8)
Main Weapon 12.7 millimeter (13mm)
Max Speed 110.0 km/h
Range 1000.0 km
Overview (Deagel)
Group Wheeled Armored Vehicles
Status Cancelled
Origin Switzerland
Contractor General Dynamics European Land Systems
Initial Operational Capability (IOC) 2014
Total Production ?
Specifications (Deagel)
Crew 3
Troops 9
Wheel Drive 8
Wheels 8
Dimensions — Main Gun Caliber 12.7 millimeter
Mass — Combat Weight 27,000 kilogram
Performance — Max Range 1,000 kilometer
Power — Power 520 hp
Speed — Top Speed 110 kph
Gear (Deagel)
Item 1 Weapon Stations: Protector (1)
Variants
Variant 1 Piranha III 6x6
Variant 2 Piranha III 8x8
Variant 3 Piranha III 10x10
Variant 4 Piranha 3 CBRN
Variant 5 Piranha 3+
Details
Country of Origin Switzerland
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
Width
Height
Weight
27000 kg
