Wisent

Wisent

Tactical Vehicles
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Wisent
Designation
Wisent
Alternate Designation
GFF Class 4
Equipment Type
Tactical Vehicles
Manufacturer
Rheinmetall Defence
Date of Introduction
2012
Description

The Wisent is a GFF class 4 vehicle combining high mobility with excellent protection against ballistic, landmine, improvised explosive device (IED), chemical, bacteriological, radiological and nuclear (CBRN) threats. It is based on a non-COTS (Commercial Off The Shelf) special chassis oriented to military requirements available in 6x6, 8x8 and 10x10 configurations. Besides mission modules, the Wisent also accepts integration of a remote control weapon station. The road testing phase began in October 2008 and series production could begin as early 2012 in Kassel, Germany. The Wisent vehicle family has been designed with a high degree of modularity for very low lifecycle costs. The heavily protected, air-conditioned multipurpose build-on module of the 8x8 version can be powered either by a high-performance motor generator unit or externally via a multi-voltage connection, thus enabling autonomous dismounted operation with no need to keep the engine running. Switching mission modules takes roughly 45 minutes. The Wisent 10x10 can serve as a platform for heavy equipment modules, or it can transport two 10-ft containers, in which case a built-in vehicle crane assures autonomous loading and unloading as well as a hazardous goods transport capability. The loading bay of the 6 x 6 version, which features drop-down sides, makes loading and unloading cargo easy. Wisent is powered by a MAN D2066 engine developing 324 kW.

Ground Specifications
Crew 2
Troop Capacity 12
Max Speed 105.0 km/h
Overview (Deagel)
Group Tactical Vehicles
Status Under Development
Also Known As GFF Class 4
Origin Germany
Contractor Rheinmetall Defence
Initial Operational Capability (IOC) 2012
Total Production ?
Specifications (Deagel)
Crew 2
Troops 12
Wheel Drive 8
Wheels 8
Energy — Max Torque 2,100 Nm
Mass — Max Weight 26 ton
Percentage — Gradient 60 %
Percentage — Side Slope 30 %
Performance — Ditch Crossing Ability 1.9 meter
Performance — Fording Depth 1.2 meter
Power — Power 324 kW
Speed — Top Speed 105 kph
Details
Country of Origin Germany
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
Width
Height
Weight
26000 kg
