Centauro VBM Recovery

Recovery & Repair Vehicles

Spotted an error? Sign in to suggest an edit.

Basic Information

Name

Centauro VBM Recovery

Designation

Centauro VBM Recovery

Alternate Designation

—

Equipment Type

Recovery & Repair Vehicles

Manufacturer

Iveco Defence Vehicles

Date of Introduction

2012

Description

The Centauro VBM Recovery is a new version of the Centauro VBM infantry fighting vehicle intended to serve as engineer vehicle as well as for recovery and repair of damaged armored vehicles on the battlefield. The vehicle can be equipped with two 7.62mm machine guns for self-defense purposes. The vehicle features NBC protection, a 100 meters hydraulic winch, hydraulic crane, anti-tank mine and Improvised Explosive Device (IED) protection, rear ramp, frontal blade, smoke grenades 8x80mm, anti-mine seats, laser warning system, etc. The Centauro VBM Recovery vehicle is powered by an IVECO 8262 6V turbocharged after cooler diesel engine rated at 405 KW (550-hp). So far, the Spanish Army is the only known operator for this version.

Ground Specifications

Crew 4

Mobility Type Wheeled (8x8)

Main Weapon 7.62mm machine guns (8mm)

Max Speed 110.0 km/h

Range 800.0 km

Overview (Deagel)

Group Recovery & Repair Vehicles

Status Active

Origin Italy

Contractor Iveco Defence Vehicles

Initial Operational Capability (IOC) 2012

Total Production ?

Specifications (Deagel)

Crew 4

Wheel Drive 8

Wheels 8

Degree — Approach Angle 30 °

Degree — Departure Angle 35 °

Dimensions — Ground Clearance 410 millimeter

Dimensions — Height 2.8 meter

Dimensions — Length 8.3 meter

Dimensions — Main Gun Caliber 7.6 millimeter

Dimensions — Wheelbase 2.5 meter

Dimensions — Width 3.0 meter

Energy — Max Torque 2,100 Nm

Mass — Empty Weight 23,000 kilogram

Mass — Max Weight 30,000 kilogram

Mass — Payload 7,000 kilogram

Performance — Fording Depth 1.5 meter

Performance — Max Range 800 kilometer

Performance — Turning Radius 9 meter

Power — Power 405 kW

Speed — Top Speed 110 kph

Variants

Variant 1 Centauro

Variant 2 Centauro VBM

Variant 3 Centauro VBM Recovery

Variant 4 Centauro Draco

Variant 5 Centauro 155/39 LW

Variant 6 Centauro VBM Mortar Carrier

Variant 7 Centauro AIFV/OWS 30 Freccia

Variant 8 Centauro II

Variant 9 Centauro VBM Command Post

Variant 10 Centauro VBM PLUS

Details

Country of Origin Italy

Sources

deagel.com: https://www.deagel.com/x/x/a000412

Classification

Domain

Ground

Equipment Status

Active

Dimensions

Length

8.3 m

Width

3 m

Height

2.8 m

Weight

30000 kg

Operators (2)

Italy

Spain
