Cantabria

Cantabria

Replenishment Ships
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Cantabria
Designation
Cantabria
Alternate Designation
Nuship Supply
Equipment Type
Replenishment Ships
Manufacturer
Navantia
Date of Introduction
2010
Description

The Spanish Navy's Cantabria Buque de Aprovisionamiento de Combate (BAC) or Combat Supplier Ship is a double hull design military replenishment ship capable of delivering fluids (water, oil, etc) or solids (food, ammunition, etc) to naval combat groups. Besides, she can be used as a floating hospital, for disaster relief or for fighting against sea pollution. A flight deck at stern allows for operation of a single rotary-wing aircraft. Having a displacement of 20,000 tons, two 10,890 KW engines drive the ship at speeds of up to 22 knots and allow to cross ranges of over 6,000 nautical miles. The Spanish Navy awarded the construction contract to Navantia in July 2005, the ship was launched on July 21, 2008 in the San Fernando Puerto Real shipyard (Spain), and is scheduled for commissioning by July/September 2009. Australia ordered two ships in 2016.

Naval & Littoral Specifications
Crew 122
Displacement 19500.00 tonnes
Beam 23.00 m
Draft 8.00 m
Max Speed 21.0 knots
Overview (Deagel)
Group Replenishment Ships
Status Active
Also Known As Nuship Supply
Origin Spain
Contractor Navantia
Initial Operational Capability (IOC) July 29, 2010
Total Production 3
Specifications (Deagel)
Crew 122
Dimensions — Beam 23 meter
Dimensions — Draft 8 meter
Dimensions — Length 174 meter
Mass — Full Displacement 19,500 ton
Performance — Max Range 6,000 nautical mile
Power — Total Combined Power 21.8 MW
Speed — Economical Speed 13 knot
Speed — Top Speed 21 knot
Gear (Deagel)
Item 1 ASW Helicopters: SH-3D (2)
Item 2 Civil Helicopters: AB212 (3)
Item 3 Utility & Transport Helicopters: NH90 TTH (2)
Details
Country of Origin Spain
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
174 m
Width
23 m
Height
Weight
19500000 kg
Operators (2)
Spain
Australia
