PARS IV 8x8 Turkish New Generation Wheeled Armoured Vehicle (NGWAV)

PARS

Multipurpose Armored Vehicle
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
PARS IV 8x8 Turkish New Generation Wheeled Armoured Vehicle (NGWAV)
Designation
PARS
Alternate Designation
PARS IV 8x8 New Generation Wheeled Armoured Vehicle (NGWAV)
Equipment Type
Multipurpose Armored Vehicle
Manufacturer
FNSS
Date of Introduction
2021
Description

The PARS IV 8x8 Turkish New Generation Wheeled Armoured Vehicle (NGWAV) has been updated to adapt to various combat environments and to incorporate constantly evolving technologies, providing its users with tactical advantages on the battlefield. The vehicle is designed to adapt to today's and future hybrid warfare conditions, which combine symmetric and asymmetric threats. The elements that determine the operational capabilities of the PARS IV 8x8 in the field —protection, firepower, mobility, and electronic infrastructure —were adapted to multiple operational scenarios. Thanks to its modular structure, the PARS IV 8x8 has been designed to be configured in various variants that can serve as an infantry fighting vehicle, reconnaissance vehicle, command and control vehicle, personnel carrier, mortar carrier, combat engineering vehicle, CBRN vehicle, and recovery vehicle. The two-man driver’s front cabin of the PARS IV 8x8 allows for operation day and night in all terrain and weather conditions, and provides more than 180°of visibility and a high level of driving safety under armour. Panoramic periscopes at the front of the vehicle, as well as driving and thermal cameras at the front and rear, provide the driver and commander with high situational awareness. This allows performing all kinds of tasks safely under armour protection, without opening the driver's hatch. The PARS IV 8x8 superior mobility is due to its power unit, the balanced load distribution, and the fully independent, height-adjustable, hydropneumatics suspensions designed to support every mission. Thanks to the all-wheel steering system, the vehicle can turn in a radius as long as its length and can easily manoeuvre in urban areas. The modular armour system and special hull design provide the highest ballistic, mine, and IED protection in its class. The ballistic protection level can also be increased according to users' requirements. The PARS IV 8x8 NG-WAV offers a combination of the highest mobility and protection within the PARS family, along with the ability to engage the evolving threats of the modern battlefield.

Ground Specifications
Crew 9
Mobility Type Wheeled (8x8)
Engine Diesel
Max Speed 100.0 km/h
Range 600.0 km
System
Alternative Designation PARS IV 8x8 New Generation Wheeled Armoured Vehicle (NGWAV)
Type New Generation Wheeled Armoured Vehicle (NGWAV)
Manufacturer FNSS
Configuration 8x8
Crew 9 + 3 (Inc. Gunner, Driver & Commander)
Dimensions
Length 8.4 m
Width 3.1 m
Height 2.5 m
Weight, Combat 30,000 kg
Automotive
Engine Name INA
Engine Type Diesel
Engine Power INA
Maximum Road Speed 100 km/h
Creep Speed 5 km/h
Range 600 km
Gradient 60%
Side Slope 30%
Angle of Approach 35°
Angle of Departure 35°
Vertical Obstacle 0.7 m
Trench Crossing 2 m
Turning Radius 8.5 m
Fording Depth 1.5 m
Suspension System Independent, Double Wishbone, Hydro- Pneumatic Suspension with Ride Height Control
Number of Axles 4 ea
Driven Axles All Wheel Drive
Steered Axles 1, 2, 3, 4
Transfer Case 2 Speed
Service Brakes Pneumatic and ABS at Each Wheel
Parking Brakes Integral to Driveline, Spring Activated, Hydraulically Controlled
Main Weapon System
Note Manned and Remote Controlled Turrets, Mortar and/or Missile Systems from Various Types and Origin Can be Integrated.
Protection
Ballistic Protection STANAG 4569 (Level Classified)
Mine Protection STANAG 4569 (Level Classified)
IED Protection STANAG 4569 (Level Classified)
Laser Warning System Optional
Gunshot Detection System Standard
Smoke Grenade Dischargers 12 ea
Automatic Fire Suppression System Standard
CBRN Protection System Standard
A/C and Heater Standard
Details
Country of Origin Turkey
Category Land
Land
Filter Label
P
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
8.4 m
Width
3.1 m
Height
2.5 m
Weight
30000 kg
Operators (1)
Turkey
