AC-32-08 Russian Unmanned Aerial Vehicle (UAV)

AC-32-08

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
AC-32-08 Russian Unmanned Aerial Vehicle (UAV)
Designation
AC-32-08
Alternate Designation
AC-32-08
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Aeromax Group
Date of Introduction
2022
Description

**AC-32-08 Russian Unmanned Aerial Vehicle (UAV)** The AC-32-08 is a compact unmanned aerial vehicle (UAV) that meets all modern drone requirements. It is capable of performing a variety of tasks, including high-precision photography and real-time visual and thermal monitoring. The UAV's body is constructed from composite materials, significantly enhancing its durability and reliability in harsh operating conditions. The versatility of the AC-32-08 allows for the installation of the company's own cameras and thermal imagers, as well as the use of customer-supplied payloads. The aircraft can fly for up to 3 hours on a single charge. Its modular design enables it to be transported using any vehicle, with a flight preparation time of no more than 10 minutes. Key Features: - High-precision aerial photography - Multispectral photography - Thermal imaging - Real-time monitoring - In-line checks during emergencies - Exploration tasks

Air & Air Defense Specifications
Engine Electric
Max Speed 120.0 km/h
Range 130.0 km
Endurance 3.00 hrs
Service Ceiling 5000 m
Wingspan 2.00 m
Payload Capacity 0 kg
System
Alternate Designation AC-32-08
Type Unmanned Aerial Vehicle (UAV)
Manufacturer Aeromax Group
Payload Capacity 0.9 kg
Multipurpose Payload AC- 170/30/19T Multipurpose payload AC-170/30/19T combines visual and thermal imaging matrices. This helps to reduce the camera weight and allows for twice as much data to be received during the flight, hence increasing the efficiency of air inspection.
Professional Thermal Imaging Camera AC-130/40T The AC-130/40T possesses a function of real-time temperature measurement and when saving photos of an object each pixel of the picture contains information about temperature.
Dimensions
Length INA
Height INA
Wingspan 2.0 m
Maximum Takeoff Weight 4.5 to 6 kg
Automotive
Engine Name INA
Engine Type Electrical motor
Engine Power INA
Maximum Speed 120 km/h
Maximum Range 130 km
The Radius of the Radio Channel and Video Line Action 70 km
Service Ceiling 5,000 m
Wind limit speed, no more 15 m/s
Endurance 3 hours
Details
Country of Origin Russia
Category UAVs
Air > UAVs
Filter Label
A
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
2 m
Height
Weight
4.5 kg
Operators (1)
Russia
