Ob-Class (Project 320/320 II Class) Russian Navy Hospital Ship
Ob-Class
Oceanographic Research Vessel
Other



Basic Information
Name
Ob-Class (Project 320/320 II Class) Russian Navy Hospital Ship
Designation
Ob-Class
Alternate Designation
Ob-Class; Project 320/320 II Class
Equipment Type
Oceanographic Research Vessel
Manufacturer
—
Date of Introduction
1978
Description
Ob-Class (Project 320 Class) Russian Navy Hospital Ship are purpose-built hospital ships. The third, fourth and projected fifth units of the class are part of Project B-320 II, modifications of the original Project 320 design. The Polish-built ships are civilian-manned but carry naval medical staffs. The four ships of the Ob-class hospital ships were designed to provide medical and recreational facilities. They were also employed as personnel transports. They have civilian crews but carry uniformed naval medical personnel. The ships are fully equipped with surgical equipment. Later two units are Project 320 II, implying a modification to the basic design; the external differences are minor.
Naval & Littoral Specifications
Crew
124
Beam
19.40 m
Draft
6.50 m
Variants
Ob'
Commissioned: 1980
Status: Decommissioned in 1997
Fleet: Pacific Fleet
Enisey
Commissioned: 1981
Status: Active
Fleet: Black Sea Fleet
Svir`
Commissioned: 1989
Status: Active
Fleet: Northern Fleet
Irtysh
Commissioned: 1990
Status: Active
Fleet: Pacific Fleet
System
Alternative Designation
Ob-Class; Project 320/320 II Class
Type
Navy Hospital Ship
Builder
Adolf Warski Shipyard, Szczecin, Poland
Crew
124 ea
Medical Personnel
83 ea
Passengers
300 patients or 650 passengers
Operating Rooms
7 x Operating Rooms
Medical Berthing
100 x beds plus 200 x berths for recuperating personnel. Additional patients can be accommodated on an emergency basis.
Dimensions
Length
152.60 m
Beam
19.40 m
Draft
6.50 m
Displacement, Standard
9,430 tons
Displacement, Full Load
11,623 tons
Propulsion System
Engine Name
2 x Zgoda-Sulzer type 12ZV 40/48
Engine Type
Diesel
Engine Power
15,600 total bhp
Generators
4 x diesel-generators x1000 kW
Maximum Range
10,000 nm at 20 knots
Maximum Speed
20 knots
Endurance
INA
Communication
VHF Radios
2 x VHF Radios
Radio Direction Finder
1 x Rumb Radio Direction Finder
Main Weapon System
Note
There are no weapons mounted onboard the Ob-Class (Project 320/320 II Class) Russian Navy Hospital Ships.
Radar Systems
Navigation Radar
3 x Don-2 Navigation Radars
Aviation
Aviation Facilities
1 x Helipad and 1 x A hangar is provided for a single helicopter for casualty evacuation.
Helicopters
1 x Ka-25PS or 1 x Ka-27PS
Protection
Hull
INA
Countermeasures
No
NBC Water Washdown System
Yes
Details
Country of Origin
Russia
Category
Support Ships
Naval > Support Ships
Filter Label
O
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
152.6 m
Width
—
Height
—
Weight
—
Operators (1)
Russia
