DF-12 (Dongfeng 12) Chinese Close-Range Ballistic Missile

Dong Feng 12

Close-Range Ballistic Missile
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
DF-12 (Dongfeng 12) Chinese Close-Range Ballistic Missile
Designation
Dong Feng 12
Alternate Designation
Dong Feng 12; NATO: CSS-X-15; DF-12
Equipment Type
Close-Range Ballistic Missile
Manufacturer
Prime contractor: Sanjiang Space Group, China Chinese Academy of Launch Vehicle Technology (CALT), Beijing, China
Date of Introduction
1983
Description

The DF-12 (Dongfeng 12) Chinese Close-Range Ballistic Missile is a road-mobile, solid-fuel, short-range ballistic missile (SRBM). Previously branded by the People’s Republic of China (PRC) as the M-20, the design of the DF-12 is believed to be based upon the Russian Iskander-E tactical missile system. Launched from a transporter erector launcher (TEL) capable of carrying two missiles, the DF-12 has a range of up to 280km and utilizes global positioning system guidance (GPS) to maintain a target accuracy of less than 30m. In addition to GPS maneuverability, the DF-12 is reported to possess other “built-in counter-measures” to evade ballistic missile defense (BMD) interceptors.

System
Alternate Designation Dong Feng 12; NATO: CSS-X-15; DF-12
Type Close-Range Ballistic Missile System
Manufacturer Prime contractor: Sanjiang Space Group, China Chinese Academy of Launch Vehicle Technology (CALT), Beijing, China
Mobility and Role Road-mobile/Short-Range Ballistic Missile
Propellant Single/Solid
Guidance System GPS, laser guidance/10-30m CEP
Maximum Range 280 km
Warhead Type Cluster, HE
Dimensions
Length 7.8 m
Diameter 0.75 m
Launch Weight 4,010 kg
Warhead Weight 400 kg
Details
Country of Origin China
Category Ground-Launched Ballistic Missiles (GLBM) (50 km - 300 km)
Air > Ground-Launched Ballistic Missiles (GLBM) (50 km - 300 km)
Filter Label
D
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
7.8 m
Width
0.75 m
Height
Weight
4010 kg
Operators (2)
China
Pakistan
