CV90 AMOS

Self-Propelled Howitzers

Spotted an error? Sign in to suggest an edit.

Basic Information

Name

CV90 AMOS

Designation

CV90 AMOS

Alternate Designation

Grkpbv 90, Mjolner

Equipment Type

Self-Propelled Howitzers

Manufacturer

Alvis Plc, United Defense

Date of Introduction

2013

Description

The CV90 AMOS combines the proven CV90 chassis and the high performance AMOS (Advanced MOrtar System) mortar-turret. AMOS is a high firepower twin-barrel 120mm smooth bore mortar jointly developed by Hagglunds and Patria. The CV90 AMOS provides high rate indirect fire at battalion level, while retains significant direct fire capability. In December 2010 the Finnish Army ordered 18 CV90 AMOS mortar systems with deliveries beginning in 2013. The AMOS mortar system can engage targets at more than 10 km with conventional unguided ammunition or smart ammunition such as the STRIX projectile. It also provides a multiple round simultaneous impact capability of up to 14 impacts simultaneously and provides high rates of fire. The Swedish Army ordered the conversion of 40 CV9040 armored vehicles into CV90 AMOS in December 2016. The Swedish vehicles will be known as Mjolner with deliveries due to start in 2019.

Ground Specifications

Crew 4

Mobility Type Tracked

Main Weapon 120mm smooth bore mortar (120mm)

Max Speed 70.0 km/h

Range 600.0 km

Overview (Deagel)

Group Self-Propelled Howitzers

Status Active

Also Known As Grkpbv 90, Mjolner

Origin Sweden

Contractors Alvis Plc, United Defense

Initial Operational Capability (IOC) 2013

Total Production 58

Unitary Cost USD $1.5 million

Specifications (Deagel)

Ammunition Load 90

Crew 4

Rolling Rubber Wheels 7

Dimensions — Height 2.8 meter

Dimensions — Length 6.6 meter

Dimensions — Main Gun Caliber 120 millimeter

Dimensions — Width 3.2 meter

Mass — Combat Weight 28,000 kilogram

Mass — Empty Weight 24,000 kilogram

Performance — Max Range 600 kilometer

Power — Power 600 shp

Rate — Max Rate of Fire 26 roundperminute

Speed — Top Speed 70 kph

Time — SetUp Time 30 second

Gear (Deagel)

Item 1 Optronic Systems: UTAAS (1)

Item 2 Projectiles: STRIX

Item 3 Weapon Stations: AMOS (1)

Variants

Variant 1 CV9040

Variant 2 CV9040C

Variant 3 CV9040 AAV

Variant 4 CV90120

Variant 5 CV90 FOV

Variant 6 CV90 FCV

Variant 7 CV90105

Variant 8 CV9030

Variant 9 CV9030 MkII

Variant 10 CV9035 MkIII

Variant 11 CV9030 COM

Variant 12 CV90 AMOS

Variant 13 CV90 Sting

Variant 14 CV90 Armadillo

Variant 15 CV90 FMV

Variant 16 CV90 MkIV

Variant 17 CV90 CEV

Details

Country of Origin Sweden

Category Artillery

Land > Artillery

Sources

deagel.com: https://www.deagel.com/x/x/a000589

Classification

Domain

Ground

Equipment Status

Active

Dimensions

Length

6.6 m

Width

3.2 m

Height

2.8 m

Weight

28000 kg

Operators (2)

Sweden

Finland
