SAM-14 (SA-14 Gremlin) Iranian Man-Portable Air Defense Missile System (MANPADS)
SAM-14
Spotted an error? Sign in to suggest an edit.
Other
Basic Information
Name
SAM-14 (SA-14 Gremlin) Iranian Man-Portable Air Defense Missile System (MANPADS)
Designation
SAM-14
Alternate Designation
—
Equipment Type
—
Manufacturer
—
Date of Introduction
1978
Description
Hezbollah and Hamas Proliferation.SAM-14 (SA-14 Gremlin) Iranian Man-Portable Air Defense Missile System (MANPADS).
Ground Specifications
Crew
1
Range
6.0 km
System
Alternative Designations
9K34 Strela-3 SA-14
Target
Air Defense
Description
The 9K34 Strela-3, NATO reporting name: SA-14 Gremlin) is a man-portable air defense missile system (MANPADS) developed in the Soviet Union as a response to the poor performance of the earlier 9K32 Strela 2 (SA-7 Grail) system.
Crew
1, Normally 2 with a loader
Armament
Launcher Name
9K34 Strela-3 (SA-14 Gremlin)
Missile Name
9M36 or 9M36-1
Length
1.4 m
Diameter
75 mm
Weight
10.3 kg
Reaction Time
25 sec
Fire on the Move
Yes, in short halt
Max Range
6,000 m
Min Range
600 m
Max Altitude
6,000 m
Min Altitude
10; 0 with degraded Ph m
Fin Span
INA
Missile Speed
600 m/s
Propulsion
2-stage solid-propellant rocket
Guidance
1-color passive IR homing
Seeker Field of View
INA
Tracking Rate
INA
Warhead Type
Frag-HE
Warhead Weight
1.0 kg
Fuze Type
Contact/grazing
Probability of Hit
50 FW/50 heli Ph%
Weapons and Ammunition Types
Ready missiles
Typical Combat Load
One-man 1
Normal Dismount 2
From AD Vehicle 5
Fire Control
Sights with magnification
Launch tube has simple sights
Gunner
INA
Gunner Field of View
INA
Gunner Acquisition Range
INA
Gunner Night Sight
None standard, but available
Acquisition Range
6,000
IFF
Yes
Details
Country of Origin
Iran
Category
Man-Portable Air-Defense Systems (MANPADS)
Land > Air Defense > Man-Portable Air-Defense Systems (MANPADS)
Filter Label
S
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
1.4 m
Width
0.08 m
Height
—
Weight
10.3 kg
Operators (2)
Iran
Non-State Actors
