Anza Mk-II Pakistani Man-Portable Air-Defense System (MANPADS)

Man-Portable Air Defense System (MANPADS)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Anza Mk-II Pakistani Man-Portable Air-Defense System (MANPADS)
Designation
Alternate Designation
Equipment Type
Man-Portable Air Defense System (MANPADS)
Manufacturer
Kahuta Research Laboratories (KRL)
Date of Introduction
1995
Description

Anza Mk-II - A third generation MANPADS, believed to be based on the Chinese QW-1 MANPADS. Uses a dual-band, cross-scan infrared homing seeker to counter decoy flares. The Anza is a series of shoulder-fired, man-portable surface-to-air missiles produced by Pakistan. Guided by an infrared homing seeker, the Anza is used for short range air defense. The Anza is produced by Kahuta Research Laboratories (KRL), being one of the facility's main conventional weapons projects. Development was originally undertaken to eliminate dependence on importing expensive foreign systems. Various versions of the Anza are currently in service with the Pakistan Army, with the Mk-III version being the most recent. The Anza is also offered for export, Malaysia being its only known export customer after receiving 100 Anza Mk-I in 2002 and, later, a further 500 Anza Mk-II systems.

Air & Air Defense Specifications
Max Speed 2160.0 km/h
Range 5.0 km
Variants
Anza Mk-I The first MANPADS produced by Pakistan for use by the Pakistan Army. Development is based on the Chinese HN-5B MANPADS.
Anza Mk-II A third generation MANPADS, believed to be based on the Chinese QW-1 MANPADS.
Anza Mk-III Believed to be based on the Chinese QW-2 MANPADS
System
Name Anza Mk-II
Type Man-Portable Air-Defense System (MANPADS)
Manufacturer Kahuta Research Laboratories (KRL)
Launch Platform Vehicle or Human
Length 1.4 m
Diameter 72 mm
Weight 16.8 kg
Warhead Shaped Charge
Engine Rocket
Propellant Solid Propellant
Operational Range 500-6,000 m
Flight Altitude 30-4,000 m
Maximum Speed 600 m/s
Guidance System Infrared Homing
Details
Country of Origin Pakistan
Category Man-Portable Air-Defense Systems (MANPADS)
Land > Air Defense > Man-Portable Air-Defense Systems (MANPADS)
Filter Label
A
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
1.4 m
Width
0.07 m
Height
Weight
16.8 kg
Operators (2)
Pakistan
Malaysia
