SM39 Exocet French Short-Range Anti-Ship Cruise Missile

SM39

Spotted an error? Sign in to suggest an edit.
Basic Information
Name
SM39 Exocet French Short-Range Anti-Ship Cruise Missile
Designation
SM39
Alternate Designation
Equipment Type
Manufacturer
Date of Introduction
1973
Description

The Exocet (French pronunciation: ​[ɛɡzɔsɛ]; French for "flying fish") is a French-built anti-ship missile whose various versions can be launched from surface vessels, submarines, helicopters and fixed-wing aircraft. The Exocet is built by MBDA, a European missile company. Development began in 1967 by Nord as a ship-launched weapon named the MM 38. A few years later Aerospatiale and Nord merged. The basic body design was based on the Nord AS30 air-to-ground tactical missile. The air-launched Exocet was developed in 1974 and entered service with the French Navy five years later. The relatively compact missile is designed for attacking small- to medium-size warships (e.g., frigates, corvettes and destroyers), although multiple hits are effective against larger vessels, such as aircraft carriers. It is guided inertially in mid-flight and turns on active radar late in its flight to find and hit its target. As a countermeasure against air defence around the target, it maintains a very low altitude during ingress, staying one to two meters above the sea surface. Due to the effect of the radar horizon, this means that the target may not detect an incoming attack until the missile is only 6,000 m from impact. This leaves little time for reaction and stimulated the design of close-in weapon systems (CIWS). Its rocket motor, which is fuelled by solid propellant, gives the Exocet a maximum range of 70 kilometres (43 mi; 38 nmi). It was replaced on the Block 3 MM40 ship-launched version of the missile with a solid-propellant booster and a turbojet sustainer motor which extends the range of the missile to more than 180 kilometres (110 mi; 97 nmi). The submarine-launched version places the missile inside a launch capsule.

Variants
MM38 (surface-launched) deployed on warships. Range: 42 km. No longer produced (1970). A coast defence version known as "Excalibur" was developed in the United Kingdom and deployed in Gibraltar from 1985–1997.
AM38 (helicopter-launched tested only
AM39 (air-launched) B2 Mod 2: deployed on 14 types of aircraft (combat jets, maritime patrol aircraft, helicopters). Range between 50 and 70 km, depending on the altitude and the speed of the launch aircraft.
SM39 (submarine-launched) B2 Mod 2: deployed on submarines. The missile is housed inside a watertight launched capsule (VSM or véhicule Sous marin), which is fired by the submarine's torpedo-launch tubes. On leaving the water, the capsule is ejected and the missile's motor is ignited. It then behaves like an MM40. The missile will be fired at depth, which makes it particularly suitable for discreet submarine operations.
MM40 (surface-launched) Block 1, Block 2 and Block 3: deployed on warships and in coastal batteries. Range: 72 km for the Block 2, in excess of 180 km for the Block 3.
MM40 Block 3 In February 2004, the Délégation Générale pour l'Armement (DGA) notified MBDA of a contract for the design and production of a new missile, the MM40 Block 3. It has an improved range, in excess of 180 kilometres (97 nautical miles)—through the use of a turbojet engine, and includes four air intakes to provide continuous airflow to the power plant during high-G manoeuvres. The Block 3 missile accepts GPS guidance system waypoint commands, which allow it to attack naval targets from different angles and to strike land targets, giving it a marginal role as a land-attack missile. The Block 3 Exocet is lighter than the previous MM40 Block 2 Exocet.
System
System
Name SM 39 Exocet
Type Anti-Ship Cruise Missile
Manufacturer 1979–1999: Aérospatiale 1999–2001: Aérospatiale-Matra 2001–present: MBDA
Length 5.80 m
Diameter 348 mm
Wingspan 1.14 m
Weight 666 kg
Configuration slim, pointed cylinder cruciform cropped and swept delta mainplanes indexed in-line with small cruciform tail planes
Propulsion 2 x SNPE double-base Nitramite smokeless solid-propellant rockets. 1 x Epervier booster with 2.4 sec burn. 1 x Eole V sustainer with 200-220 sec burn
Speed 594 kt (684 mph; 1,100 km/h) or Mach 0.93
Maximum Range 50 km
Minimum Range 4 km
Peak Altitude 50 m
Warhead 363 lb. (165 kg) Hexolite blast fragmentation
Sensor and Fire Control TRT AHV-7 radio altimeter inertial navigation during first part of flight Electronique Marcel Dassault ADAC or Super ADAC I/J-band active radar homing in terminal phase that begins search approx 5.4 nm (6.2 mi.; 10 km) from target's estimated position.
Details
Country of Origin France
Category Short-Range Cruise Missiles (SRCM) (Less than 600 km)
Air > Short-Range Cruise Missiles (SRCM) (Less than 600 km)
Filter Label
S
Classification
Domain
Air & Air Defense
Equipment Status
Active
Operators (31)
France
Germany
Turkey
India
Iran
Pakistan
Brazil
South Africa
Argentina
Brunei
Bulgaria
Cameroon
Chile
Colombia
Cyprus
Ecuador
Egypt
Greece
Indonesia
Kuwait
Libya
Malaysia
Morocco
Oman
Peru
Qatar
Thailand
Tunisia
United Arab Emirates
Uruguay
Vietnam
