Raider Israeli Unmanned Aerial Vehicle (UAV)

Raider

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Raider Israeli Unmanned Aerial Vehicle (UAV)
Designation
Raider
Alternate Designation
Raider
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Heven Co
Date of Introduction
2024
Description

The Raider Israeli Unmanned Aerial Vehicle (UAV) is the pinnacle of hydrogen-powered UAV innovation.Combining exceptional endurance, modular design,and unparalleled payload capacity, this twin-fuselage,VTOL platform delivers unmatched performance fordiverse missions. Built for precision and adaptability,the Raider redefines operational efficiency fordefense, logistics, ISR, and more. Its modular twin-fuselage design improves aerodynamic stability and enables quick configuration changes without extensive recalibration. Additional features include vertical takeoff and landing (VTOL), rapid assembly within 15 minutes, and a modular battery system for improved hovering capabilities.

Air & Air Defense Specifications
Engine Hydrogen
Cruise Speed 103.0 km/h
Range 1000.0 km
Endurance 12.00 hrs
Wingspan 7.00 m
Payload Capacity 23 kg
System
Alternate Designation Raider
Type Unmanned Aerial Vehicle (UAV)
Manufacturer Heven Co.
Payload Capacity 23.0 kg
Vertical Take-Off and Landing (VTOL) Capacity Yes
Note In addition to endurance and payload capabilities, the Raider offers near-silent operation with low thermal and acoustic signatures, making it well-suited for sensitive missions. Its ability to monitor large areas with multi-platform, multi-sensor configurations enhances its effectiveness for persistent surveillance and force protection. On-site hydrogen generation further supports energy independence, enabling continuous operations in remote or resource-limited environments.
Dimensions
Length INA
Height INA
Wingspan 7.0 m
Maximum Takeoff Weight 119 kg
Automotive
Engine Name INA
Engine Type Hydrogen
Engine Power INA
Maximum Speed INA
Cruise Speed 103 km/h
Maximum Range 1,000 km
Service Ceiling INA
Endurance 12 hours
Details
Country of Origin Israel
Category UAVs
Air > UAVs
Filter Label
R
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
7 m
Height
Weight
119 kg
Operators (2)
United States
Israel
