NRUAV

NRUAV

Reconnaissance Rotorcrafts
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
NRUAV
Designation
NRUAV
Alternate Designation
Naval Rotary UAV
Equipment Type
Reconnaissance Rotorcrafts
Manufacturer
Israel Aerospace Industries Ltd. (IAI)
Date of Introduction
Description

The IAI Naval Rotary UAV (NRUAV) is a tactical unmanned rotorcraft designed to provide over the horizon targeting (OTHT), real-time battle damage assessment (BDA) and intelligence, surveillance and reconnaissance (ISR) missions. It is based on IAI's Malat-made Helicopter Modification Suite (HeMoS) platform. The NRUAV features automatic take-off and landing (ATOL) from warships and fully redundant system. It is equipped with a line-of-sight data link and can accommodate a variety of payloads such as electro-optical sensors, multi-mode radars, electronic support measures (ESM) or Communications Intelligence (COMINT) payload. The NRUAV can remain on station for six hours at ranges of 150 kilometers carrying a 220 kg payload.

Air & Air Defense Specifications
Max Speed 185.2 km/h
Range 150.0 km
Service Ceiling 4572 m
Overview (Deagel)
Group Reconnaissance Rotorcrafts
Status Active
Also Known As Naval Rotary UAV
Origin Israel
Contractor Israel Aerospace Industries Ltd. (IAI)
Total Production ?
Specifications (Deagel)
Crew 0
Main Rotor Blades 3
Tail Rotor Blades 2
Dimensions — Height 3.0 meter
Dimensions — Length 12.8 meter
Dimensions — Main Rotor Diameter 11.0 meter
Dimensions — Tail Rotor Diameter 1.9 meter
Mass — Max Takeoff Weight 2,200 kilogram
Mass — Payload 220 kilogram
Performance — Ceiling 15,000 foot
Performance — Max Range 150 kilometer
Speed — Loiter Speed 60 knot
Speed — Top Speed at High Altitude 100 knot
Time — Flight Endurance 6 hour
Details
Country of Origin Israel
Category Rotary Wing Aircraft
Air > Rotary Wing Aircraft
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
12.8 m
Width
Height
3 m
Weight
2200 kg
Operators (1)
Israel
