Abhay Class (Project 1241PE Class) Indian Corvette
Abhay Class
Corvette
Spotted an error? Sign in to suggest an edit.
Other
Basic Information
Name
Abhay Class (Project 1241PE Class) Indian Corvette
Designation
Abhay Class
Alternate Designation
Abhay Class; Project 1241PE Class; Pauk II Class
Equipment Type
Corvette
Manufacturer
—
Date of Introduction
1989
Description
The Abhay Class (Project 1241PE Class) Indian Corvette are the customised variants of the Soviet Pauk-class corvettes. The class was primarily intended for coastal patrol and anti-submarine warfare. The last ship of the class is expected to be decommissioned by 2025.
Naval & Littoral Specifications
Crew
75
Beam
10.20 m
Draft
3.80 m
Variants
Abhay
Commissioned: 1989
Status: Active
Ajay
Commissioned: 1990
Status: Decommissioned in 2022.
Akshay
Commissioned: 1990
Status: Decommissioned in 2022.
Agray
Commissioned: 1991
Status: Decommissioned in 2017
System
Alternative Designation
Abhay Class; Project 1241PE Class; Pauk II Class
Type
Corvette
Builder
Volodarski, Rybinsk
Crew
Enlisted: 75; Officers: 7
Dimensions
Length
58.5 m
Height
INA
Beam
10.2 m
Draft
3.8 m
Displacement, Full Load
635 tons
Propulsion System
Engine Name
2 x MTU 16V 1163 TB93
Engine Type
Diesel
Engine Power
12,900 hp
Maximum Range
2,400 n miles (4,444.8 km) (2,761.9 miles) at 14 kt (25.9 km/h) (16.1 mph)
Maximum Speed
25 kt (46.3 km/h) (28.8 mph)
Main Weapon Systems
Missile System
Surface-to-Air Missiles (SAM)
9K32/9K32M Strela-2/2M (SA-N-5 Grail); portable launchers for 12 9M32/9M32M missiles; manual aiming, IR homing to 2.2/4.2 km (1.2/2.3 n miles) at Mach 1.26/1.47; altitude up to 1,500/2,300 m; warhead 1.17 kg.
Gun System
Guns
1 x AK-176 76 mm/59; 120 rds/min to 15 km (8 n miles); weight of shell 5.9 kg. 1 x AK-630 30 mm/65; 6 barrels; 3,000 rds/min combined to 4 km (2.2 n miles); weight of shell 0.39 kg.
Torpedo System
Torpedo Tubes
4 x 533 mm (2 twin) tubes.
Torpedoes
SET-65E; anti-submarine; passive homing to 13 km (7 n miles) at 35 kt; electric; warhead 205 kg; depth to 350 m.
Anti-Submarine Mortars
RPS Uragan System
2 x RBU-1200 5-barrel launcher; RGB-12 rocket-propelled depth charges; range 400–1,200 m; depth 15–350 m; warhead 30 kg.
Radar Systems
Air/Surface Search Radar
1 x MR-352E Pozitiv-E (Cross Dome); E/F-band.
Fire Control Radar
1 x MR-123 Vympel/Bagira (Bass Tilt); I-band.
Navigation Radar
1 x Pechora; I-band.
Sonar System
Sonar
1 x MGK-345 (Rat Tail) VDS (on transom); attack; high frequency.
Protection
Hull
INA
Physical Countermeasures
1 x PK-16 DLS; 2 x 16-barrel 82 mm fixed launchers; IR flares and chaff.
Electronic Countermeasures
No
NBC Water Washdown System
Yes
Details
Country of Origin
India
Category
Naval
Naval
Filter Label
A
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
58.5 m
Width
10.2 m
Height
—
Weight
635000 kg
Operators (1)
India
