ZBD04A
ZBD04A
Tracked Armored Vehicles
Basic Information
Name
ZBD04A
Designation
ZBD04A
Alternate Designation
Type 04A, ZBD-04A
Equipment Type
Tracked Armored Vehicles
Manufacturer
—
Date of Introduction
2014
Description
The ZBD04A IFV features a two-man turret-mounted 100mm main gun with a 30mm automatic cannon as well as a 7.62mm machine gun. The 100m gun is able to fire the Bastion anti-tank missile. The vehicle features a rear door for the seven infantrymen squad carried by this armored vehicle. Compared with the basic ZBD04, the new variant features a grilled fence around the turret for additional protection and a Beidou global satellite navigation receptor also installed onto the turret. The ZBD04A was being tested by the PLA at theLanzhou Military Region in April 2014.
Ground Specifications
Crew
3
Troop Capacity
7
Max Speed
75.0 km/h
Range
600.0 km
Overview (Deagel)
Group
Tracked Armored Vehicles
Status
Active
Also Known As
Type 04A, ZBD-04A
Origin
China
Initial Operational Capability (IOC)
2014
Total Production
2,000
Specifications (Deagel)
Crew
3
Rolling Rubber Wheels
6
Troops
7
Dimensions — Height
2.5 meter
Dimensions — Length
7.2 meter
Dimensions — Main Gun Caliber
100 millimeter
Dimensions — Width
3.2 meter
Mass — Combat Weight
20,000 kilogram
Performance — Max Range
600 kilometer
Power — Power
590 hp
Speed — Top Speed
75 kph
Speed — Top Swimming Speed
6 kph
Variants
Variant 1
ZBD04
Variant 2
ZBD-97 ARV
Variant 3
ZBD04A
Variant 4
ZBD04A AT
Variant 5
ZBD04A RV
Variant 6
ZBD04 APC
Details
Country of Origin
China
Sources
deagel.com: https://www.deagel.com/x/x/a002983
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.2 m
Width
3.2 m
Height
2.5 m
Weight
20000 kg
Operators (1)
China
