Sherpa 3A

Sherpa 3A

Tactical Vehicles
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Sherpa 3A
Designation
Sherpa 3A
Alternate Designation
MPCV (Multi Purpose Combat Vehicle), Sherpa Light HI
Equipment Type
Tactical Vehicles
Manufacturer
Renault Trucks Defense
Date of Introduction
—
Description

The Sherpa 3A is a 4x4, all-terrain, light armored vehicle based on the Sherpa 3 military truck system. The all protected Sherpa 3A is intended to provide support to rapid reaction forces carrying a 3-ton payload. It features a reduced silhouette, a 7m3 armored body providing protection against ballistic threats and mines and a four-man crew. The Sherpa 3A light armored vehicle is air transportable and air droppable. The 10-ton class Sherpa 3A is powered by a 4-cylinder Euro 4 220-hp diesel engine which allows for a top speed of 110 kph on road and a cruising range of 800 km at 70 kph with a 200-l fuel tank. Optional equipment includes: air conditioning, radio, add-on armor kits, engine speed control, central tire inflation system, adjustable steering wheel, roof-mounted 7.62mm or 12.7mm machine gun, heating system, etc.

Ground Specifications
Crew 4
Mobility Type Wheeled (4x4)
Main Weapon 12.7 millimeter (13mm)
Max Speed 110.0 km/h
Range 800.0 km
Overview (Deagel)
Group Tactical Vehicles
Status Active
Also Known As MPCV (Multi Purpose Combat Vehicle), Sherpa Light HI
Origin France
Contractor Renault Trucks Defense
Total Production ?
Specifications (Deagel)
Crew 4
Wheel Drive 4
Wheels 4
Dimensions — Ground Clearance 330 millimeter
Dimensions — Height 2.1 meter
Dimensions — Length 5.3 meter
Dimensions — Main Gun Caliber 12.7 millimeter
Dimensions — Width 2.3 meter
Mass — Empty Weight 9,300 kilogram
Mass — Max Weight 13,300 kilogram
Mass — Payload 2,900 kilogram
Performance — Max Range 800 kilometer
Power — Power 220 hp
Speed — Cruise Speed 70 kph
Speed — Top Speed 110 kph
Volume — Cabin Volume 7 metric ton
Volume — Fuel Tank Capacity 200 liter
Variants
Variant 1 Sherpa 3
Variant 2 Sherpa 3A
Variant 3 Sherpa 2
Variant 4 Sherpa A2M
Details
Country of Origin France
Sources

deagel.com: https://www.deagel.com/x/x/a001945

Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
5.3 m
Width
2.3 m
Height
2.1 m
Weight
13300 kg
Operators (4)
France
Italy
Egypt
Qatar
