LUMTAS

LUMTAS

Anti-Tank Guided Missiles
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
LUMTAS
Designation
LUMTAS
Alternate Designation
L-UMTAS
Equipment Type
Anti-Tank Guided Missiles
Manufacturer
ROKETSAN
Date of Introduction
2015
Description

The Laser UMTAS missile, also known as LUMTAS or L-UMTAS, is a derivative of the UMTAS long-range anti-tank missile designed for the T-129 ATAK combat helicopter. Besides, LUMTAS can be installed on a wide range of platforms such as helicopters, light armored vehicles, close air support aircraft, Unmanned Air Vehicles (UAVs), ground fixed-position and surface ships. It is designed to engage armored targets day/night and in adverse weather conditions at ranges between 500 to 8,000 meters using an insensitive tandem warhead suitable against explosive reactive armor (ERA) protected vehicles. The LUMTAS can be lock-on target before and after launch. Its guidance system combines inertial measurement unit, two-way RF data-link to transfer the target area information after launch to the helicopter's weapon system operator, and a laser seeker. Once launched the missile is autonomously guided to the locked target with the data-link giving the opportunity to update the target or hit zone. LUMTAS missile is fully compatible with all modern attack helicopters compliant with MIL-STD-1760 standard.

Ground Specifications
Range 8.0 km
Overview (Deagel)
Group Anti-Tank Guided Missiles
Status Active
Also Known As L-UMTAS
Origin Turkiye
Contractor ROKETSAN
Initial Operational Capability (IOC) 2015
Total Production ?
Specifications (Deagel)
Dimensions — Diameter 160 millimeter
Dimensions — Length 1,800 millimeter
Mass — Weight 37.5 kilogram
Performance — Max Range 8,000 meter
Performance — Min Range 500 meter
Variants
Variant 1 UMTAS
Variant 2 OMTAS
Variant 3 LUMTAS
Details
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
Width
Height
Weight
37.5 kg
