Teal 2 American Unmanned Aerial Vehicle (UAV)
Teal 2
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
Teal 2 American Unmanned Aerial Vehicle (UAV)
Designation
Teal 2
Alternate Designation
Teal 2
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
TEAL; A Red Cat Company
Date of Introduction
2023
Description
The Teal 2 American Unmanned Aerial Vehicle (UAV) is a military-grade small unmanned aircraft system (sUAS) developed by Teal Drones, a subsidiary of Red Cat, a drone manufacturing company based in the US.
Air & Air Defense Specifications
Crew
1
Engine
Battery
Max Speed
37.0 km/h
Range
5.0 km
Endurance
30.00 hrs
Service Ceiling
3048 m
Payload Capacity
2 kg
System
Alternate Designation
Teal 2
Type
Unmanned Aerial Vehicle (UAV) (C)
Manufacturer
TEAL; A Red Cat Company
Crew
1 ea
Payload Capacity
Teal 2 is equipped with a dual-axis electro-optic (EO)/infrared (IR) Gimbal system with a forward-looking infrared (FLIR) Hadron 640R sensor, which delivers top-tier thermal imaging resolution in a compact design.
Flight Controller
MAVLink Compliant
FLIR
The FLIR imaging allows the operator to visualize what is concealed from the naked eye. The EO modifies light into electronic signals for full visibility, while the IR detects targets, tracks movement and determines threats more easily.
The drone offers a complete range of thermal palettes for total visibility, including White Hot for operating at night, Black Hot to display body heat as a clear image with a high level of detail and Hottest isotherm for high-contrast environmental conditions. It also offers the Arctic color palette, which provides lighter color contrasted against a darker shading to quickly detect heat sources and Iron bow for quick identification of thermal anomalies.
AI Capabilities
The Teal 2 airframe has been designed as an open platform to accommodate software technologies, such as Athena’s machine learning and artificial intelligence (AI).
Camera
The multi-vehicle command and control feature provides a 360° view of a target or the ability to conduct intelligence, surveillance and reconnaissance on multiple targets.
Security
The drone employs high-level security measures by utilizing AES-256 encryption to ensure the confidentiality of data and communication and safeguard against unauthorized access.
Dimensions
Length
INA
Height
INA
Width
INA
Weight
1.25 kg
Note
The drone’s compact and sturdy design makes it suitable for easy transport in a rucksack, enabling deployment in even the most demanding conditions.
Automotive
Engine Name
INA
Engine Type
Battery
Engine Power
INA
Maximum Speed
37 km/h
Maximum Range
5 km
Service Ceiling
3,048 m
Endurance
30 min
Image Sources
Details
Country of Origin
United States
Category
UAVs
Air > UAVs
Filter Label
T
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
—
Width
—
Height
—
Weight
1.25 kg
Operators (1)
United States
