SLS Evolved Lift Capability

SLS Evolved Lift Capability

Space Launch Systems
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
SLS Evolved Lift Capability
Designation
SLS Evolved Lift Capability
Alternate Designation
SLS Block 2
Equipment Type
Space Launch Systems
Manufacturer
Aerojet Rocketdyne, Boeing, Northrop Grumman, United Launch Alliance
Date of Introduction
2031
Description

The SLS Evolved Lift Capability will be designed to carry bulky and heavyweight payloads, as well as important cargo, equipment and science experiments to Earth's orbit and support deep space exploration. Besides, the SLS will serve as backup system for transportation services to the International Space Station (ISS). It has a lift capacity for 130 metric tons or 143 tons. The SLS Evolved Lift Capability features a core stage, upper stage and the cargo fairing. The core stage uses RS-25D/E rocket engines derived from the Space Shuttle Main Engines along with two solid rocket boosters (SRBs). The upper stage is equipped with the J-2X rocket engine. At liftoff the rocket has 20 percent more thrust than the Saturn V heavy launch vehicle. The program was delayed with the first launch expected in 2020. As of 2024, the first launch is planned for 2030 or later.

Overview (Deagel)
Group Space Launch Systems
Status Under Development
Also Known As SLS Block 2
Origin United States of America
Contractors Aerojet Rocketdyne, Boeing, Northrop Grumman, United Launch Alliance
Initial Operational Capability (IOC) 2031
First Flight 2030
Total Production ?
Unitary Cost USD $5 billion
Specifications (Deagel)
Number of Stages 2
Dimensions — Height 111 meter
Dimensions — Rocket Diameter 8.4 meter
Mass — Max Lift-off Thrust 4,173 ton
Mass — Max Lift-off Weight 2,948 ton
Mass — Payload to LEO 130 ton
Mass — Payload to Moon 46 ton
Volume — Payload Capacity 130 metric ton
Gear (Deagel)
Item 1 Rocket Engines: J-2X
Item 2 Rocket Engines: RS-25D/E (2)
Item 3 Rocket Engines: Solid Rocket Booster (2)
Variants
Variant 1 SLS Initial Lift Capability
Variant 2 SLS Evolved Lift Capability
Details
Country of Origin United States
Sources

deagel.com: https://www.deagel.com/x/x/a002712

Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
111 m
Width
8.4 m
Height
111 m
Weight
2948000 kg
Operators (1)
United States
