T 815-7 4x4
T 815-7 4x4
Military Trucks
Basic Information
Name
T 815-7 4x4
Designation
T 815-7 4x4
Alternate Designation
T 815-780R59, T 815-7APR59, T 815-7L0R59
Equipment Type
Military Trucks
Manufacturer
TATRA
Date of Introduction
—
Description
The 19-ton class TATRA T 815-7 4x4 is available in cargo/troop carrier (T 815-7L0R59), universal container carrier (T 815-780R59), high mobility heavy duty fuel filler with 5,300 liters (T 815-780R59), and high mobility heavy duty chassis (T 815-7APR59). The range of engines available for these vehicles provide a power output from 240 kW to 270 kW and a maximum speed on road of 115 kph. The payload varies from 4,500 kg in the fuel filler version to 11,060 kg in the heavy duty chassis.
Ground Specifications
Mobility Type
Wheeled (4x4)
Max Speed
115.0 km/h
Range
500.0 km
Overview (Deagel)
Group
Military Trucks
Status
Active
Also Known As
T 815-780R59, T 815-7APR59, T 815-7L0R59
Origin
Czechia
Contractor
TATRA
Total Production
?
Specifications (Deagel)
Wheel Drive
4
Wheels
4
Degree — Approach Angle
42 °
Degree — Departure Angle
29 °
Dimensions — Ground Clearance
380 millimeter
Dimensions — Height
2.7 meter
Dimensions — Length
8.1 meter
Dimensions — Track
2.1 meter
Dimensions — Width
2.5 meter
Energy — Max Torque
1,550 Nm
Mass — Cargo
8,500 kilogram
Mass — Max Gross Train Weight
37,000 kilogram
Mass — Max Weight
19,000 kilogram
Percentage — Gradient
75 %
Percentage — Side Slope
45 %
Performance — Ditch Crossing Ability
0.90 meter
Performance — Fording Depth
1.5 meter
Performance — Max Range
500 kilometer
Performance — Step Climbing Ability
0.50 meter
Performance — Turning Radius
9.3 meter
Power — Power
257 kW
Speed — Top Speed
115 kph
Volume — Fuel Tank Capacity
220 liter
Variants
Variant 1
T 815-7 4x4
Variant 2
T 815-7 6x6
Variant 3
T 815-7 8x8
Details
Country of Origin
Czech Republic
Sources
deagel.com: https://www.deagel.com/x/x/a002521
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
8.1 m
Width
2.5 m
Height
2.7 m
Weight
37000 kg
Operators (2)
Czech Republic
Slovakia
