VP11 Chinese 4x4 Mine-Resistant Ambush Protected (MRAP)
VP11
Mine-Resistant Ambush Protected (MRAP)
Other
Basic Information
Name
VP11 Chinese 4x4 Mine-Resistant Ambush Protected (MRAP)
Designation
VP11
Alternate Designation
VP11
Equipment Type
Mine-Resistant Ambush Protected (MRAP)
Manufacturer
NORINCO
Date of Introduction
2014
Description
The VP11 Chinese 4x4 Mine-Resistant Ambush Protected (MRAP) is an MRAP-type vehicle built using a monocoque hull with a V-shaped bottom. It is designed to transport a body of troops into an area on patrol and for light combat missions. Alternatively, the vehicle could be used for local command, reconnaissance, and border security operations with differing mission systems as required by the customer.
Ground Specifications
Crew
3
Mobility Type
Wheeled (4x4)
Main Weapon
7.62 mm UW1 machine gun
Engine
Diesel
Max Speed
120.0 km/h
Range
800.0 km
System
Alternative Designation
VP11
Type
Mine-Resistant Ambush Protected (MRAP)
Manufacturer
NORINCO
Configuration
4x4
Crew
3 ea
Passengers
4 ea
Dimensions
Length
5.30 m
Width
2.50 m
Height
2.40 m
Weight, Combat
10,000 kg
Automotive
Engine Name
INA
Engine Type
Diesel
Engine Power
INA
Maximum Range
800 km
Maximum Speed
120 km/h
Amphibious
No
Angle of Approach
46°
Angle of Departure
36°
Gradient
60%
Side Slope
30%
Vertical Step
0.40 m
Trench
INA
Fording
0.80 m
Main Weapon System
Note
1 × roof-mounted 7.62 mm UW1 machine gun
Protection
Armor
STANAG 4569 Level 1
Applique Armor
STANAG 4569 Level 2 by applying Applique armor
NBC Protection
Optional
Smoke Equipment
INA
Details
Country of Origin
China
Category
Mine-Resistant Ambush Protected (MRAP)
Land > Infantry Vehicles > Mine-Resistant Ambush Protected (MRAP)
Filter Label
V
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
5.3 m
Width
2.5 m
Height
2.4 m
Weight
10000 kg
Operators (3)
China
Tajikistan
United Arab Emirates
