Z60 Chinese Autonomous Surface Vehicle (ASV)
Z60
Autonomous Surface Vehicle (ASV)
Other
Basic Information
Name
Z60 Chinese Autonomous Surface Vehicle (ASV)
Designation
Z60
Alternate Designation
Z60
Equipment Type
Autonomous Surface Vehicle (ASV)
Manufacturer
Chinese Defense Equipment Co.
Date of Introduction
2023
Description
The Z60 Chinese Autonomous Surface Vehicle (ASV) is mainly responsible for the guard, patrol, surveillance, reconnaissance, dislodge, rescue, transit, of the surrounding water area of mother ships, harbors, base stations, islands, etc. The USV can reach the target area by autonomous navigation or taken by mother ships.
Naval & Littoral Specifications
Beam
2.70 m
Draft
0.60 m
System
Alternative Designation
Z60
Type
Autonomous Surface Vehicle
Builder
Chinese Defense Equipment Co.
Crew
Autonomous
Working Mode
Autonomous Navigation, Remote-Control
Payload Capacity
0.8 tons
Communication Distance
1 km (remote-control unit); 20 km (base station)
Broadband Bandwidth
2 mbps (Private network)
Anti-Jamming Capability
Frequency Hopping communication anti-jamming
Discovery Distance
5 km
Identification Distance
2 km
Dimensions
Length
7.5 m
Height
2.2 m
Beam
2.7 m
Draft
0.6 m
Displacement, Full Load
4.3 tons
Propulsion System
Engine Name
INA
Engine Type
INA
Engine Power
INA
Communication Range
1 km (remote-control unit); 20 km (base station)
Maximum Speed
40 knots (74.08 km/h)
Endurance
555.6 km
Protection
Hull
INA
Countermeasures
INA
NBC Water Washdown System
INA
Image Sources
Details
Country of Origin
China
Category
Naval
Naval
Filter Label
Z
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
7.5 m
Width
2.7 m
Height
2.2 m
Weight
4300 kg
Operators (1)
China
