CH-10 Chinese Unmanned Aerial Vehicle (UAV)

CH-10

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
CH-10 Chinese Unmanned Aerial Vehicle (UAV)
Designation
CH-10
Alternate Designation
CH-10
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
CASC
Date of Introduction
2018
Description

The CH-10 Chinese Unmanned Aerial Vehicle (UAV) can be used without the need for a runway, which expands its operational scope compared to traditional fixed-wing drones. It is capable of both reconnaissance and combat roles and is designed to accompany large and medium-sized naval ships or armed forces. The UAV can perform multiple types of intelligence missions, including but not limited to reconnaissance, detection, communications relay, search, target identification, and relay guidance. It is designed for long-range reconnaissance and surveillance missions, among other applications.

Air & Air Defense Specifications
Max Speed 320.0 km/h
Cruise Speed 200.0 km/h
Range 1200.0 km
Endurance 5.00 hrs
Service Ceiling 7000 m
Wingspan 6.70 m
Payload Capacity 48 kg
System
Alternate Designation CH-10
Type Unmanned Aerial Vehicle (UAV)
Manufacturer China Aerospace Science and Technology Corp (CASC)
Payload Capacity 48.0 kg
Dimensions
Length INA
Height INA
Wingspan 6.7 m
Maximum Takeoff Weight 435 kg
Automotive
Engine Name INA
Engine Type INA
Engine Power INA
Maximum Speed 320 km/h
Cruise Speed 200-240 km/h
Maximum Range 1,200 km
Service Ceiling 7,000 m
Cruise Altitude 3,000-5,000 m
Endurance 5 hours
Details
Country of Origin China
Category UAVs
Air > UAVs
Filter Label
C
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
6.7 m
Height
Weight
435 kg
Operators (1)
China
