Centauro AIFV/OWS 30 Freccia
Centauro AIFV/OWS 30 Freccia
Wheeled Armored Vehicles
Basic Information
Name
Centauro AIFV/OWS 30 Freccia
Designation
Centauro AIFV/OWS 30 Freccia
Alternate Designation
—
Equipment Type
Wheeled Armored Vehicles
Manufacturer
Consortium Iveco-Oto Melara
Date of Introduction
2020
Description
The Centauro AIFV/OWS 30 Freccia combines the Centauro family armored chassis and hull with an overhead HITFIST OWS 30mm unmanned weapon station. Besides, the vehicle is equipped with a more powerful engine driving an automatic gearbox and enhanced by 3-axle steering to achieve outstanding mobility. The remotely operated 30mm can take out a wide range of armored vehicles and cause outstanding damage to heavy armored targets such as main battle tanks. The Centauro Advanced Infantry Fighting Vehicle was introduced by the Consortium Iveco-Oto Melara in June 2016. Italy ordered a first batch of 25 vehicles in December 2019.
Ground Specifications
Crew
1
Troop Capacity
10
Mobility Type
Wheeled (8x8)
Main Weapon
30mm (30mm)
Max Speed
110.0 km/h
Range
800.0 km
Overview (Deagel)
Group
Wheeled Armored Vehicles
Status
Active
Origin
Italy
Contractor
Consortium Iveco-Oto Melara
Initial Operational Capability (IOC)
2020
Total Production
25
Specifications (Deagel)
Crew
1
Troops
10
Wheel Drive
8
Wheels
8
Degree — Approach Angle
40 °
Degree — Departure Angle
40 °
Dimensions — Ground Clearance
410 millimeter
Dimensions — Height
3.2 meter
Dimensions — Length
8.1 meter
Dimensions — Main Gun Caliber
30 millimeter
Dimensions — Wheelbase
2.5 meter
Dimensions — Width
3 meter
Energy — Max Torque
2,100 Nm
Mass — Combat Weight
30.5 ton
Mass — Empty Weight
22 ton
Mass — Payload
8.5 ton
Percentage — Gradient
60 %
Percentage — Side Slope
30 %
Performance — Ditch Crossing Ability
2 meter
Performance — Fording Depth
1.5 meter
Performance — Max Range
800 kilometer
Performance — Step Climbing Ability
0.60 meter
Performance — Turning Radius
9 meter
Power — Power
550 hp
Speed — Top Speed
110 kph
Volume — Cabin Volume
12.5 metric ton
Gear (Deagel)
Item 1
Weapon Stations: HITFIST (1)
Variants
Variant 1
Centauro
Variant 2
Centauro VBM
Variant 3
Centauro VBM Recovery
Variant 4
Centauro Draco
Variant 5
Centauro 155/39 LW
Variant 6
Centauro VBM Mortar Carrier
Variant 7
Centauro AIFV/OWS 30 Freccia
Variant 8
Centauro II
Variant 9
Centauro VBM Command Post
Variant 10
Centauro VBM PLUS
Details
Country of Origin
Italy
Sources
deagel.com: https://www.deagel.com/x/x/a000412
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
8.1 m
Width
3 m
Height
3.2 m
Weight
30500 kg
Operators (1)
Italy
