Holland

Holland

Patrol Boats
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Holland
Designation
Holland
Alternate Designation
Ocean Patrol Vessel
Equipment Type
Patrol Boats
Manufacturer
Damen Shipyard Galati, Royal Schelde Group
Date of Introduction
2011
Description

The Royal Netherlands Navy (RNLN) Ocean Patrol Vessels (OPVs) are flexible, long-endurance ships with a high performance, designed for tasks including embargo operations, counter drugs trafficking, and humanitarian missions. The key element for these patrol vessels is the Thales Integrated Mast which contains state-of-the-art surveillance sensors. The RNLN plans call for the procurement of four vessels with the lead ship to be commissioned at the end of 2010. Thales Integrated Mast will contain the sensors SMILE, SEASTAR, and GATEKEEPER. The non-rotating radars SMILE and SEASTAR have been designed to detect airborne and surface littoral targets respectively that are difficult to detect by a typical rotating radar. These sensors support missions in coastal waters thanks to their inherent longer time on target and capability to operate in complicated atmospheric conditions. GATEKEEPER is a 360-degree full coverage electro-optical surveillance system.

Naval & Littoral Specifications
Crew 90
Displacement 3750.00 tonnes
Beam 16.00 m
Draft 4.60 m
Max Speed 21.5 knots
Overview (Deagel)
Group Patrol Boats
Status Active
Also Known As Ocean Patrol Vessel
Origin Netherlands
Contractors Damen Shipyard Galati, Royal Schelde Group
Initial Operational Capability (IOC) May 12, 2011
Total Production 4
Specifications (Deagel)
Crew 90
Number of Aircraft 1
Number of Engines 2
Dimensions — Beam 16 meter
Dimensions — Draft 4.6 meter
Dimensions — Length 108 meter
Dimensions — Main Gun Caliber 76 millimeter
Mass — Full Displacement 3,750 ton
Performance — Max Range 5,000 nautical mile
Power — Total Combined Power 10,800 kW
Speed — Cruise Speed 15 knot
Speed — Top Speed 21.5 knot
Gear (Deagel)
Item 1 ASW Helicopters: NH90 NFH (1)
Item 2 Naval Gun Systems: 76/62 Compact (1)
Item 3 Optronic Systems: GATEKEEPER (1)
Item 4 Radar Systems: SEASTAR (1)
Item 5 Radar Systems: SMILE (1)
Item 6 Weapon Stations: HITROLE (2)
Details
Country of Origin Netherlands
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
108 m
Width
16 m
Height
Weight
3750000 kg
Operators (1)
Netherlands
