GC-45 Canadian 155mm Towed Gun-Howitzer
GC-45
Towed Gun
Other
Basic Information
Name
GC-45 Canadian 155mm Towed Gun-Howitzer
Designation
GC-45
Alternate Designation
GC-45
Equipment Type
Towed Gun
Manufacturer
Space Research Corporation, Noricum, NORINCO
Date of Introduction
1977
Description
The GC-45 (Gun, Canada, 45) is a 155 mm howitzer designed by Gerald Bull's Space Research Corporation (SRC) in the 1970s. Versions were produced by a number of companies during the 1980s, notably in Austria and South Africa. The most publicized use of the design was in Iraq, where the GHN-45 variant used by some Iraqi artillery units had a longer range than any coalition cannon systems. This initially caused considerable worry on the part of the allied forces in the Persian Gulf War
Ground Specifications
Crew
6
Variants
GHN-45
Licensed Austrian copy, made by Noricum. These were the first mass-produced GC-45s.
GHN-45 with Auxiliary Power Unit (APU)
Independence from a separate prime mover is achieved with a 110-hp Porsche APU that can be mounted on the front of the carriage in about two days. The APU is equipped with headlights, a right-side driver's seat, and two x 30-liter gasoline tanks.
155-mm Type WA 021 (PLL01)
This is a Chinese variant based on GHN-45 technology obtained from Austria.
System
Alternative Designation
GC-45
Type
Towed Gun-Howitzer
Caliber
155 mm
Manufacturer
Space Research Corporation, Noricum, NORINCO
In Service
1977-Present
Family
GC-45
Carriage
6x6 truck
Crew
6 ea
Displacement Time
1.5 min
Emplacement Time
1.5 min
Dimensions
Length, Traveling
9.72 m
Length, Barrel
7.05 m
Length, Rifling
5.82 m
Width, Traveling
2.50 m
Width, FIring
9.93 m
Height
2.05 m
Weight, Combat
10,070 kg
Ground Clearance
310 mm
Trail type
Split
Automotive Requirement
Prime Mover
6x6 truck
Road Towing Speed
90 km/h
Cross-Country Towing Speed
50 km/h
Auto-propulsion speed
20 km/h
Auxiliary Power Unit (Optional)
Engine Name
Porsche, model: INA
Engine Type
2.3 liter Petrol engine
Engine Power
120 hp
Maximum Road Speed
30 km/h
Maximum Cross-Country Speed
15 km/h
Auto-Propulsion Range (on roads)
130 km/h
Fuel Capacity
30 liters
Maximum Range a one Tank of Fuel
130 km
Gradient
40 %
Note
Independence from a separate prime mover is achieved with a 110-hp Porsche APU that can be mounted on the front of the carriage in about two days. The APU is equipped with headlights, a right-side driver's seat, and 2 x 30-liter gasoline tanks.
Gun-Howitzer System
Cannon
Name
GC-45, 155mm Gun-Howitzer
Type
Gun-Howitzer
Gun Bore
155 mm
Length, Barrel
7.05m (45 calibers)
Loader Type
Manual
Maximum Firing Range
39.6 with Base Bleed
Max Elevation
+72 deg
Min Elevation
-5 deg
Traverse Range
70 km
Traverse Right
40 deg
Traverse Left
30 deg
Mussle Brake Type
fitted w/multi-baffle muzzle brake
Breech Type
semi-automatic with pneumatic rammer
Bore Type
155-mm/45-cal
Max Rate of Fire, Burst
3 rds in 16 seconds
Max Rate of Fire, Normal
2 rds/min
Max Rate of Fire, Maximum
7 rds/min
Ammunition (Option 1)
Type
ERFB
Caliber
155 mm
Projectile Weight
45.4 kg
Muzzle Velocity
897 m/s
Maximum Range
30,000 m
Basic Load
INA
Ammunition (Option 2)
Name
SN-101
Type
155 mm
Projectile Weight
42.3 kg
Muzzle Velocity
897 m/s
Maximum Range
25,100 m
Basic Load
INA
Ammunition (Option 3)
Name
SN-107
Type
155 mm
Projectile Weight
42.3 kg
Muzzle Velocity
897 m/s
Maximum Range
17,800 m
Basic Load
INA
Fire Control
Name
INA
Computerized FCS
No
Direct Fire
No
Indirect Fire
Yes
Collimator
INA
Details
Country of Origin
Canada
Category
Towed Gun/Howitzer Artillery Systems
Land > Artillery > Towed Gun/Howitzer Artillery Systems
Filter Label
G
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
—
Width
—
Height
2.05 m
Weight
10070 kg
Operators (16)
China
Israel
Turkey
Iran
Pakistan
South Africa
Austria
Iraq
Jordan
Kuwait
Malaysia
Oman
Saudi Arabia
Singapore
Thailand
United Arab Emirates
