An-12 (Cub) Russian Transport Aircraft

The Antonov An-12 (Russian: Антонов Ан-12; NATO reporting name: Cub) is a four-engined turboprop transport aircraft designed in the Soviet Union. It is the military version of the Antonov An-10 and has many variants. For more than three decades the An-12 was the standard medium-range cargo and paratroop transport aircraft of the Soviet air forces. A total of 1,234 were eventually built. Developed from the Antonov An-8, the An-12 was a military version of the An-10 passenger transport. The first prototype An-12 flew in December 1957 and entered Soviet military service in 1959. Initially, the aircraft was produced at the State Aviation Factory in Irkutsk. From 1962, production was transferred to Tashkent, where 830 were built. Later, production moved to Voronezh and Kazan. In military use, the An-12 has the capacity for up to 100 fully equipped paratroopers or 20,000 kg (44,090 lb) of cargo, which is loaded through the rear loading ramp/door. In terms of configuration, size, and capability, the aircraft is similar to the United States-built Lockheed C-130 Hercules. Soviet military and former-Soviet An-12s have a defensive tail gun turret. In the 1960s, China purchased several An-12 aircraft from the Soviet Union, along with a license to assemble the aircraft locally. Due to the Sino-Soviet split, the Soviet Union withdrew its technical assistance and the first flight of a Chinese-assembled An-12 was delayed until 1974. After USSR ceased production in 1973, the Xi'an Aircraft Company and Xi'an Aircraft Design Institute reverse-engineered the An-12 for local production. In 1981, the Chinese version of the An-12, designated Y-8, entered production. Since then, the Y-8 has become one of China's most popular military and civilian transport/cargo aircraft, with many variants produced and exported. A Tu-16/H-6 bomber navigator cockpit design was chosen for the Y-8 instead of the original An-12 shorter navigator cockpit design, as the H-6 bomber had been in serial production for some time. Although the An-12 is no longer in use either in Russia or in Ukraine, the Y-8 is upgraded and produced in China. The latest Y8-F600 is a joint venture between the Shaanxi Aircraft Company, Antonov Aeronautical Scientific-Technical Complex (ASTC), and Pratt & Whitney Canada. The Y8-F600 has a redesigned fuselage, western avionics, PW150B turboprop engines with an R-408 propeller system, and a two-crew glass cockpit.
