Armidale Class Australian Patrol Boat

Armidale Class

Patrol Boat
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Armidale Class Australian Patrol Boat
Designation
Armidale Class
Alternate Designation
Armidale Class
Equipment Type
Patrol Boat
Manufacturer
Date of Introduction
2005
Description

The Armidale Class Australian Patrol Boat fleet are named after Australian cities and towns with close links with Navy heritage. The Armidale Class was named to coincide with the 60th commemoration of the sinking of the original HMAS Armidale (I). The Armidale Class provides the Navy an improved capability to intercept and apprehend vessels in a greater range of sea conditions than the earlier patrol boat classes; the Fremantle Class and the Attack Class. Most importantly, Patrols Boats are a primary enabler of the Australian Defence Force's contribution to Operation SOVEREIGN BORDERS, which is a whole of the government's effort to protect Australia's borders and offshore interests.

Naval & Littoral Specifications
Crew 21
Beam 9.70 m
Draft 2.70 m
Variants
Armidale Commissioned: 2005 Status: Active
Larrakia Commissioned: 2006 Status: Active
Bathurst Commissioned: 2006 Status: Active
Albany Commissioned: 2006 Status: Active
Pirie Commissioned: 2006 Status: Decommissioned 2021
Maitland Commissioned: 2006 Status: Decommissioned 2022
Ararat Commissioned: 2006 Status: Decommissioned 2022
Broome Commissioned: 2007 Status: Active
Bundaberg Commissioned: 2007 Status: Decommissioned 2014
Wollongong Commissioned: 2007 Status: Active
Childers Commissioned: 2007 Status: Active
Launceston Commissioned: 2007 Status: Active
Maryborough Commissioned: 2007 Status: Active
Glenelg Commissioned: 2008 Status: Decommissioned 2002
System
Alternative Designation Armidale Class
Type Patrol Boat
Builder Austal
Crew 21 crew standard, 29 crew maximum, maximum 150 persons onboard
Dimensions
Length 56.8 m
Height INA
Beam 9.7 m
Draft 2.7 m
Displacement, Standard 300 tons
Displacement, Full Load INA
Propulsion System
Engine Name 2 × MTU 4000 16V
Engine Type Diesel
Engine Power 6,225 hp
Maximum Range 3,000 nautical miles (5,600 km at 12 knots (22 km/h)
Maximum Speed 25 knots (46 km/h)
Endurance 21 days standard, 42 days maximum
Main Weapon System
Note 1 × Rafael Typhoon stabilized gun mount fitted with a Mk 38 25 mm (1 in) M242 Bushmaster autocannon.
Radar Systems
Search/Navigation Radar 2 x Bridgemaster E surface search/navigation radar
Protection
Countermeasures No
NBC Water Washdown System Yes
Electronic Warfare 1 x Prism III radar warning system Toplite electro-optical detection system and 1 x Warrlock direction finding system
Details
Country of Origin Australia
Category Naval
Naval
Filter Label
A
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
56.8 m
Width
Height
Weight
Operators (1)
Australia
