AW119 Kx

AW119 Kx

Civil Helicopters
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
AW119 Kx
Designation
AW119 Kx
Alternate Designation
Equipment Type
Civil Helicopters
Manufacturer
Leonardo Helicopters
Date of Introduction
2013
Description

The AW119 Kx is the latest enhanced version of the A119 Koala single-engine helicopter with state-of-the-art integrated avionics bringing this model to a new digital era while keeping the outstanding performance, cabin space and payload characteristics of the rugged AW119Ke. The new aircraft features the Garmin G1000H glass integrated flight deck system and the very latest avionics, including synthetic vision, moving map, highway in the sky and obstacle/terrain avoidance systems, to improve situational awareness and increase safety. The aircraft is powered by a single PT6B-37A Pratt & Whitney turbine rated at 1,002-shp developing a maximum speed of 152 knots (282 km/h). The AW119Kx has the most spacious cabin in its category and with its separate cabin and cockpit areas provides true cabin class comfort. Critical systems redundancies similar to twin-engine helicopters provide high levels of safety. In addition, the AW119 Kx helicopter is well suited for law enforcement, offshore applications, fire fighting and emergency medical services. AgustaWestland unveiled its AW119 Kx helicopter at Air Medical Transport Conference (AMTC) in Seattle, USA, in October 2012. AgustaWestland plans to achieve type certification in the first quarter of 2013. The first customer for the AW119Kx is Life Flight Network, which is set to receive all of the 15 units ordered for its air medical helicopter transportation requirement during 2013.

Air & Air Defense Specifications
Crew 1
Max Speed 282.0 km/h
Overview (Deagel)
Group Civil Helicopters
Status Active
Origin Italy
Contractor Leonardo Helicopters
Initial Operational Capability (IOC) March 5, 2013
Total Production 94
Specifications (Deagel)
Crew 1
Main Rotor Blades 4
Number of Engines 1
Passengers 7
Tail Rotor Blades 2
Mass — Max Takeoff Weight 2,850 kilogram
Power — Max Power at TakeOff 1,002 shp
Speed — Top Speed at High Altitude 282 kph
Gear (Deagel)
Item 1 Turboshaft Engines: PT6B-37A (1)
Variants
Variant 1 A119 Koala
Variant 2 AW119 Ke
Variant 3 AW119 Kx
Variant 4 TH-73A Trasher
Details
Country of Origin Italy
Category Rotary Wing Aircraft
Air > Rotary Wing Aircraft
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
Height
Weight
2850 kg
Related Equipment (1)
Operators (10)
China
United States
Israel
Brazil
Australia
Chile
Latvia
Malaysia
Philippines
Portugal
