VF-32E Chinese Unmanned Aerial Vehicle (UAV)

VF-32E

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
VF-32E Chinese Unmanned Aerial Vehicle (UAV)
Designation
VF-32E
Alternate Designation
VF-32E
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Hinaray
Date of Introduction
2024
Description

The VF-32E Chinese Unmanned Aerial Vehicle (UAV) is a lightweight, fuel-powered VTOL (vertical takeoff and landing) fixed-wing drone developed by Hinaray, a Chinese manufacturer specializing in hybrid VTOL unmanned aerial systems. The VF-32E features a high-efficiency LD-70cc gasoline engine with a low-vibration, modular design, optimized for endurance and reduced maintenance. Its multi-fuel capability ensures adaptability in diverse operational environments worldwide. The system boasts a rugged, compact airframe that merges fixed-wing efficiency with VTOL hybrid versatility, enabling rapid deployment in the field. Emphasizing military-grade wind resistance and independence from battery reliance, the platform excels in remote or austere locations where extended performance is critical. The VF-32E is engineered for a range of operational scenarios, including: Power line and infrastructure inspections Agricultural crop monitoring High-precision aerial mapping and surveying Search and rescue operations Rural logistics and medical supply transport Environmental and wildlife monitoring The VF-32E marks Hinaray's debut in the lightweight tactical UAV sector, offering a rapidly deployable, modular, and combat-capable VTOL platform. Its compact design, quick assembly, and moderate payload capacity make it ideal for forward-deployed missions demanding swift response without extensive ground support.

Air & Air Defense Specifications
Engine Gasoline (4 hp)
Max Speed 120.0 km/h
Range 80.0 km
Endurance 5.00 hrs
Service Ceiling 4000 m
Wingspan 3.60 m
Payload Capacity 10 kg
System
Alternate Designation VF-32E
Type Unmanned Aerial Vehicle (UAV)
Manufacturer Hinaray
Payload Capacity 10 kg
Dimensions
Length INA
Height INA
Wingspan 3.6 m
Maximum Takeoff Weight 32 kg
Automotive
Engine Name LD-70cc
Engine Type Gasoline Engine
Engine Power 4.3–6 hp
Fuel Compatibility Multi-fuel compatible
Maximum Speed 120 km/h
Cruise Speed INA
Maximum Range 80 km
Service Ceiling 4,000 m
Endurance 5 hours (with 2.5 kg payload) / 300 minutes
Details
Country of Origin China
Category UAVs
Air > UAVs
Filter Label
V
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
3.6 m
Height
Weight
32 kg
Operators (1)
China
