MSTA-S

MSTA-S

Self-Propelled Howitzers
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
MSTA-S
Designation
MSTA-S
Alternate Designation
2S19, 2S19M1, 2S19M1-155
Equipment Type
Self-Propelled Howitzers
Manufacturer
Uraltransmash
Date of Introduction
1989
Description

The MSTA-S, also known as 2S19, is a 152mm highly mobile self-propelled howitzer designed to engage stationary and moving targets deep inside enemy territory. The variety of targets include manpower, light and heavy armored vehicles, field fortifications, air defense sites and command and control stations. The MSTA-S 152mm 2A64 primary gun features 47-caliber long barrel which allow a maximum range of 24 to 29 kilometers firing conventional or rocket assisted projectiles (RAP) respectively. It has been developed on the basis of the T-72 tank power pack and T-80 Main Battle Tank (MBT) chassis with the addition of a gun turret comprising the 152mm main gun and related systems. It was designed to replace the 122mm and 152mm self-propelled howitzers in service with the Soviet Army but the Soviet Union's collapse and lack of funds have made these plans to fail. The MSTA-S self-propelled howitzer entered service in 1989. The Russian Army is the largest operator so far.

Ground Specifications
Crew 5
Mobility Type Tracked
Main Weapon 152mm 2A64 primary gun (152mm)
Max Speed 60.0 km/h
Range 500.0 km
Overview (Deagel)
Group Self-Propelled Howitzers
Status Active
Also Known As 2S19, 2S19M1, 2S19M1-155
Origin Russia
Contractor Uraltransmash
Initial Operational Capability (IOC) 1989
Total Production ?
Specifications (Deagel)
Ammunition Load 50
Caliber Multiple 47
Crew 5
Rolling Rubber Wheels 6
Degree — Max Elevation 68 °
Dimensions — Ground Clearance 450 millimeter
Dimensions — Height 3.0 meter
Dimensions — Length 11.9 meter
Dimensions — Main Gun Caliber 152 millimeter
Dimensions — Width 3.4 meter
Mass — Combat Weight 42,000 kilogram
Percentage — Gradient 47 %
Performance — Ditch Crossing Ability 2.8 meter
Performance — Main Gun Max Range 24,700 meter
Performance — Max Range 500 kilometer
Performance — Max Range firing RAP 29,000 meter
Performance — Step Climbing Ability 0.50 meter
Power — Power 840 hp
Rate — Max Rate of Fire 8 roundperminute
Speed — Cross Country Speed 22 kph
Speed — Top Speed 60 kph
Time — SetUp Time 3 minute
Gear (Deagel)
Item 1 Projectiles: Krasnopol
Item 2 Projectiles: Krasnopol-M
Variants
Variant 1 MSTA-S
Variant 2 MSTA-SV
Details
Country of Origin Russia
Category Artillery
Land > Artillery
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
11.9 m
Width
3.4 m
Height
3 m
Weight
42000 kg
Operators (5)
Russia
Ukraine
Azerbaijan
Syria
Venezuela
