Soyuz-5

Space Launch Systems

Spotted an error? Sign in to suggest an edit.

Basic Information

Name

Soyuz-5

Designation

Soyuz-5

Alternate Designation

Baiterek, Irtysh

Equipment Type

Space Launch Systems

Manufacturer

Starsem, TsSKB Progress

Date of Introduction

2028

Description

The Soyuz-5 is a medium-class carrier rocket with a launch weight of about 530-ton and a 17-ton payload designed as the replacement for the Soyuz-2 rocket. The new space rocket will be powered by more eco-friendly fuel engines provided by Progress based upon liquefied natural gas. The Soyuz-5 flexibility will allow it to turn into a heavy-class rocket adding side blocks. The Soyuz-5 is not intended as a contender for the Angara rocket family which is under development within Russia as well. The Soyuz-5 draft design is slated for completion by the end of 2015 and first launch is scheduled for late 2023. In August 2023, the first launch was delayed to December 24, 2025. In October 2024, it was delayed to 2026. The first flight was completed on April 30, 2026.

Overview (Deagel)

Group Space Launch Systems

Status Under Development

Also Known As Baiterek, Irtysh

Origin Russia

Contractors Starsem*, TsSKB Progress

Initial Operational Capability (IOC) 2028

First Flight April 30, 2026

Total Production 3

Specifications (Deagel)

Crew 0

Number of Stages 2

Dimensions — Height 62 meter

Dimensions — Rocket Diameter 4.1 meter

Mass — Max Lift-off Thrust 800 ton

Mass — Max Lift-off Weight 530 ton

Mass — Payload to GTO 5,000 kilogram

Mass — Payload to LEO 18,000 kilogram

Gear (Deagel)

Item 1 Rocket Engines: RD-169 (1)

Item 2 Rocket Engines: RD-171MV (1)

Variants

Variant 1 Soyuz-5

Variant 2 Soyuz-6

Details

Country of Origin Russia

Sources

deagel.com: https://www.deagel.com/x/x/a004720

Classification

Domain

Air & Air Defense

Equipment Status

Active

Dimensions

Length

62 m

Width

4.1 m

Height

62 m

Weight

530000 kg

Operators (1)

Russia
