Project 667BDR

Project 667BDR

Ballistic Submarines
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Project 667BDR
Designation
Project 667BDR
Alternate Designation
Delta III, Kalmar
Equipment Type
Ballistic Submarines
Manufacturer
—
Date of Introduction
1976
Description

The Project 667B (Delta Class NATO designation) is the second generation of Project 667A (Yankee Class NATO designation) strategic submarines of which 34 units were produced with the first boat entering service in 1967. Their nuclear propulsion provides outstanding performance over conventionally-powered submarines as well as longer endurance while submerged. The first Project 667B boat was commissioned in 1973 and since then 43 boats were commissioned for the Russian/Soviet Navy. The development of Project 667BDR, Kalmar Russian designation and Delta III NATO designation, began in 1972 with the first boat entering service in 1976. It was equipped with 16 RSM-50 (R-29R) ballistic missiles carrying three nuclear warheads each. The R-29R was the first MIRVed SLBM introduced by the Soviet Union. The Soviet Navy commissioned 14 boats, the last one in 1982. Currently, the Russian Navy operates six Delta III ballistic submarines. It is expected that sooner two or more of these ships are decommissioned due to aging. By 2010, the remaining ships could be replaced by the Borey-class submarines with the first boat joining the Russian fleet in 2006.

Naval & Littoral Specifications
Crew 130
Beam 12.00 m
Overview (Deagel)
Group Ballistic Submarines
Status Active
Also Known As Delta III, Kalmar
Origin Russia
Initial Operational Capability (IOC) 1976
Total Production 14
Specifications (Deagel)
Crew 130
Number of Ballistic Missiles 16
Number of Weapons 18
Torpedo Tubes 4
Dimensions — Beam 12 meter
Dimensions — Length 155 meter
Mass — Displacement Submerged 10,600 ton
Mass — Displacement Surfaced 8,940 ton
Performance — Max Operating Depth 400 meter
Power — Power 40,000 shp
Speed — Top Speed Submerged 12.3 mps
Time — Mission Endurance 80 day
Gear (Deagel)
Item 1 Anti-Submarine Rockets: RPK-2 (18)
Item 2 Intercontinental Ballistic Missiles: RSM-50 (16)
Item 3 Torpedoes: USET-80
Variants
Variant 1 Project 667B
Variant 2 Project 667BD
Variant 3 Project 667BDR
Variant 4 Project 667BDRM
Details
Country of Origin Russia
Category Submarines
Naval > Submarines
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
155 m
Width
12 m
Height
—
Weight
—
Related Equipment (1)
Operators (1)
Russia
