Il-96-400T
Il-96-400T
Freight Airliners
Basic Information
Name
Il-96-400T
Designation
Il-96-400T
Alternate Designation
Il-496T
Equipment Type
Freight Airliners
Manufacturer
Ilyushin Aviaton Complex, VASO
Date of Introduction
2009
Description
The Il-96-400T is a stretched freighter version of the Il-96-300 airliner and features improved aerodynamics, fuel efficient PS-90A turbojet engines, increased payload capacity, improved frame design, and updated onboard avionics. The Il-96-400T is less expensive than its western counterparts such as the Boeing 777F freighter. The four PS-90A engines are rated at 16,000 kg/35,000-lb of thrust each. The Il-96-400T freighter can transport a payload of 92 tons on routes of up to 5,000 kilometers and payloads of 40 tons on routes of up to 12,000 km.
Air & Air Defense Specifications
Crew
3
Max Speed
870.0 km/h
Range
12000.0 km
Service Ceiling
12000 m
Wingspan
60.10 m
Overview (Deagel)
Group
Freight Airliners
Status
Active
Also Known As
Il-496T
Origin
Russia
Contractors
Ilyushin Aviaton Complex, VASO
Initial Operational Capability (IOC)
September 27, 2009
First Flight
August 14, 2007
Total Production
3
Specifications (Deagel)
Crew
3
Number of Engines
4
Service Life Flight Hours
60000
Service Life Flights
20000
Area — Wing Area
350 square meter
Dimensions — Cargo Compartment Length
44.9 meter
Dimensions — Fuselage Diameter
6.1 meter
Dimensions — Height
15.7 meter
Dimensions — Length
63.9 meter
Dimensions — Wingspan
60.1 meter
Mass — Cargo
92 ton
Mass — Max Takeoff Thrust
141,000 pound
Mass — Max Takeoff Weight
265 ton
Performance — Ceiling
12,000 meter
Performance — Landing Run Distance
1,650 meter
Performance — Max Range
12,000 kilometer
Performance — Take Off Run Distance
2,700 meter
Speed — Cruise Speed
870 kph
Time — Service Life
20 year
Volume — Fuel Tank Capacity
152,620 liter
Volume — Payload Capacity
776 metric ton
Gear (Deagel)
Item 1
Turbofan Engines: PS-90A1 (4)
Variants
Variant 1
Il-96-300
Variant 2
Il-96M
Variant 3
Il-96T
Variant 4
Il-96-400
Variant 5
Il-96-400T
Variant 6
Il-96-400M
Variant 7
Il-96-400TZ
Details
Country of Origin
Russia
Sources
deagel.com: https://www.deagel.com/x/x/a000195
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
63.9 m
Width
60.1 m
Height
15.7 m
Weight
265000 kg
Operators (1)
Russia
