MTGR American Tracked Unmanned Ground Vehicle (UGV)
MTGR
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
MTGR American Tracked Unmanned Ground Vehicle (UGV)
Designation
MTGR
Alternate Designation
MTGR
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Roboteam
Date of Introduction
2021
Description
The MTGR American Tracked Unmanned Ground Vehicle (UGV) is a unique and lightweight tactical robot with high maneuverability in any terrain-indoors and outdoors. The MTGR was specially designed to aid military, law enforcement and public safety units in various combat situations around the world. Whether for an EOD, Urban Warfare, Special Operations, or public safety mission – MTGR dominates the unknown
Ground Specifications
Max Speed
3.5 km/h
System
Alternate Designation
MTGR
Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Roboteam
Configuration
Tracked
Communication
Secure IP Mobile Ad-hoc network
Payload Capacity
10 kg
Payload Ports
Power (12-28V), Ethernet , Video/Audio,CAN bus, 12V I/O, 5V I/O
Video & Cameras
5 integrated cameras for 360° Real time day & night,2 cameras on manipulator & optional Mast camera(8 in total).
Sensor Tilt Module
-20° to 90° (under vehicle inspection)
Illumination Module
360° NIR illumination + front white LED+laser pointers
Operational Temperature (MIL STD.)
-4°F to 140°F / -20°C to 60° C
Audio
Microphone
Mechanical Interfaces
Multiple Piccantiny Rails for mounting accessories (disruptors, ext. cameras, wire cutter, long fingertips etc.)
Environmental
Ruggedized, IP6
Dimensions
Length
45.5 cm
Width
36.8 cm
Height
14.5 cm
Weight
8.6 kg with wheels for all-terrain operation
Automotive
Power Supply
24V MIL-STD battery
Maximum Speed
3.5 km/h
OperatingRange
500 m LOS
Endurance
3 hours
Tactical Manipulator
Degrees of Freedom
4 DOF, (shoulder, elbow,wrist, gripper)
Gripper Opening
11 cm
Weight
4 kg
Lift Capacity
5 kg , fully extended
Reach Length
49 cm
Cameras
1. Auto focus camera, Optical zoom X10. 2. Close up gripper camera
Illumination
White / NIR LED
Mechanical Interface
Quick release screws &Picatinny rails
Image Sources
Details
Country of Origin
United States
Category
Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
M
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
0.46 m
Width
0.37 m
Height
0.15 m
Weight
8.6 kg
Operators (1)
United States
