ARMAX 4x4
ARMAX 4x4
Military Trucks
Basic Information
Name
ARMAX 4x4
Designation
ARMAX 4x4
Alternate Designation
T 815-25RR45/50T, T 815-26OR45/451, T 815-26WR45/10T, T 815-26WR45/11T, T 815-26WR45/12T, T 815-26WR45/13T, T 815-26WR45/14T
Equipment Type
Military Trucks
Manufacturer
TATRA
Date of Introduction
—
Description
The ARMAX 4x4 variant includes several versions with engine output ranging from 230 to 255 kW, payload ranging from 7,200 to 9,200 kg and max gross vehicle weight from 16,500 to 17,000 kg. The 25RR45/50T features a max gross train weight of 32,500 kg versus 41,000 kg for the other members of the ARMAX 4x4 product line.
Ground Specifications
Mobility Type
Wheeled (4x4)
Max Speed
105.0 km/h
Range
1000.0 km
Overview (Deagel)
Group
Military Trucks
Status
Active
Also Known As
T 815-25RR45/50T, T 815-26OR45/451, T 815-26WR45/10T, T 815-26WR45/11T, T 815-26WR45/12T, T 815-26WR45/13T, T 815-26WR45/14T
Origin
Czechia
Contractor
TATRA
Total Production
?
Specifications (Deagel)
Wheel Drive
4
Wheels
4
Degree — Approach Angle
36 °
Degree — Departure Angle
37 °
Dimensions — Ground Clearance
360 millimeter
Dimensions — Length
7.4 meter
Dimensions — Track
2.0 meter
Dimensions — Wheelbase
4.5 meter
Dimensions — Width
2.5 meter
Energy — Max Torque
1,570 Nm
Mass — Cargo
9,200 kilogram
Mass — Max Gross Train Weight
41,000 kilogram
Mass — Max Weight
17,000 kilogram
Percentage — Gradient
100 %
Percentage — Side Slope
67 %
Performance — Ditch Crossing Ability
0.90 meter
Performance — Fording Depth
1.2 meter
Performance — Max Range
1,000 kilometer
Performance — Step Climbing Ability
0.50 meter
Performance — Turning Radius
11.5 meter
Power — Power
255 kW
Speed — Top Speed
105 kph
Volume — Fuel Tank Capacity
320 liter
Variants
Variant 1
ARMAX 4x4
Variant 2
ARMAX 6x6
Variant 3
ARMAX 8x8
Details
Country of Origin
Czech Republic
Sources
deagel.com: https://www.deagel.com/x/x/a002518
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.4 m
Width
2.5 m
Height
—
Weight
41000 kg
Operators (1)
Czech Republic
