Huon Class Australian Minehunter Coastal (MHC)
Huon Class
Multi-Role Response Vessel (MRRV)
Spotted an error? Sign in to suggest an edit.
Other
Basic Information
Name
Huon Class Australian Minehunter Coastal (MHC)
Designation
Huon Class
Alternate Designation
Huon Class
Equipment Type
Multi-Role Response Vessel (MRRV)
Manufacturer
Australian Defence Industries
Date of Introduction
1999
Description
The Huon Class Australian Minehunter Coastal (MHC) is a group of minehunters built for the Royal Australian Navy (RAN).
Naval & Littoral Specifications
Crew
6
Beam
9.90 m
Draft
3.00 m
Variants
Huon
Commissioned: 1999
Status: Active
Hawkesbury
Commissioned: 2000
Status: In reserve since 2011; for sale as of 2018
Norman
Commissioned: 2000
Status: In reserve since 2011; for sale as of 2018
Gascoyne
Commissioned: 2001
Status: Active
Diamantina
Commissioned: 2002
Status: Active
Yarra
Commissioned: 2003
Status: Active
System
Alternative Designation
Huon Class
Type
Minehunter Coastal (MHC)
Builder
Australian Defence Industries
Crew
6 officers and 34 sailors, plus up to 9 additional sailors
Dimensions
Length
52.5 m
Height
INA
Beam
9.9 m
Draft
3.0 m
Displacement, Standard
INA
Displacement, Full Load
732 tons
Propulsion System
Engine Name
1 × Fincantieri GMT BL230-BN
Engine Type
Diesel
Engine Power
1,985 bhp
Thrusters
3 × 120 hp (89 kW) Riva Calzoni azimuth thrusters with Combimac low magnetic electric motors
Maximum Range
3,000 km at 12 knots (22 km/h)
Maximum Speed
14 knots (26 km/h) on diesel
6 knots (11 km/h) on thrusters
Endurance
19 days
Main Weapon System
Note
1 × 30 mm DS30B rapid fire cannon
Auxiliary Weapon System
Note
2 x 12.7mm Heavy Machine Gun
Remotely Operated Vehicle (ROV)
Note
2 × SUTEC Double Eagle mine disposal vehicles
Radar Systems
Navigation Radar
1 x Kelvin-Hughes Type 1007 navigational radar
Sonar Systems
Mine Hunting Sonar
1 x GEC-Marconi Type 2093M variable-depth mine hunting sonar
Protection
Decoys
2 × Wallop Super Barricade decoy launchers
NBC Water Washdown System
Yes
Electronic Warfare
1 x AWADI PRISM radar warning and direction-finding system
Surveillance System
1 x Radamec 1400N surveillance system
Image Sources
Note
https://en.wikipedia.org/wiki/File:HMAS_Gascoyne_(M_85).jpg; https://navyrecognition.com/index.php/naval-news/naval-news-archive/2020/september/8950-australian-navy-hmas-gascoyne-huon-class-minehunter-ship-returns-to-sea-after-readiness-evaluation.html; https://en.wikipedia.org/wiki/Lerici-class_minehunter
Details
Country of Origin
Australia
Category
Naval
Naval
Filter Label
H
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
52.5 m
Width
9.9 m
Height
—
Weight
732000 kg
Operators (1)
Australia
