DJI MAVIC 3M Chinese Unmanned Aerial Vehicle (UAV)
DJI MAVIC 3M
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
DJI MAVIC 3M Chinese Unmanned Aerial Vehicle (UAV)
Designation
DJI MAVIC 3M
Alternate Designation
DJI MAVIC 3M
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
DJI
Date of Introduction
2022
Description
The DJI MAVIC 3M Chinese Unmanned Aerial Vehicle (UAV) is a powerful new drone weighing 951g. Packed with a Multispectral Camera and RGB Camera and it has a 43min flight time. It has features like Omnidirectional Obstacle Avoidance and 14.54km video transmission. As of 2023, this is the leading agricultural drone to scan and analyze crop growth.
Air & Air Defense Specifications
Engine
Battery (12 hp)
Max Speed
75.0 km/h
Range
32.0 km
Endurance
43.00 hrs
System
Alternate Designation
DJI MAVIC 3M
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
SZ DJI Technology Co
GNSS
GPS + Galileo + BeiDou + GLONASS (GLONASS is supported only when RTK module is enabled)
Gimbal
3-axis mechanical gimbal (tilt, roll, pan)
Camera
RGB CAMERA, MULTISPECTRAL CAMERA
Maximum Takeoff Weight
1,050 g
Sensing System
Omnidirectional binocular vision system, with an infrared sensor at the bottom of the aircraft
Video Transmission
DJI O3 Enterprise Transmission
Operating Temperature
-10° to 40° C (14° to 104° F)
Battery Charging Time
Approx. 1 hour 30 minutes
(with the included DJI USB-C Power Adapter (100W) only charging the remote controller or a USB charger at 15 V)
Approx. 2 hours
(with a USB charger at 12 V)
Approx. 2 hours 50 minutes
(with the included DJI USB-C Power Adapter (100W) charging the aircraft and remote controller simultaneously)
Dimensions
Length, Folded (Without Propellers)
223 mm
Width, Folded (Without Propellers)
96.3 mm
Height, Folded (Without Propellers)
122.2 mm
Length, Unfolded (Without Propellers)
347.5 mm
Width, Unfolded (Without Propellers)
283 mm
Height, Unfolded (Without Propellers)
139.6 mm
Weight
1,050 g
Automotive
Engine Name
INA
Engine Type
Battery
Engine Power
12 W
Maximum Speed
75km/h
Maximum Range
32 km
Service Ceiling
INA
Endurance
43 min
Max Wind Speed Resistance
12 m/s
Hovering Accuracy Range
Vertical: ±0.1 m (Vision Positioning enabled); ±0.5 m (GNSS Positioning enabled); ±0.1 m (D-RTK enabled)
Horizontal: ±0.3 m (Vision Positioning enabled); ±0.5 m (HD Positioning enabled); ±0.1 m (RTK enabled)
Image Sources
Image Sources
Details
Country of Origin
China
Category
UAVs
Air > UAVs
Filter Label
D
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
—
Width
—
Height
—
Weight
1.05 kg
Operators (3)
Russia
China
Ukraine
