HMT 400 Supacat British High Mobility Transporter (HMT)
HMT 400 Supacat
High Mobility Transporter (HMT)
Other
Basic Information
Name
HMT 400 Supacat British High Mobility Transporter (HMT)
Designation
HMT 400 Supacat
Alternate Designation
HMT 400 Supacat
Equipment Type
High Mobility Transporter (HMT)
Manufacturer
Supacat
Date of Introduction
2005
Description
Already well-proven in the harsh terrain of the Afghanistan battlefield, the 400 has a unique air suspension system that allows the selection of a variable ride height to match the terrain and also, enable internal loading within CH-47 Chinook. Supplied with an optional mine blast and ballistic protection kit, the 400 can be fitted with a variety of mission specific hampers, weapons, communications, ISTAR and force protection equipment to suit a wide range of operational roles.
Ground Specifications
Crew
1
Mobility Type
Wheeled (4x4)
Engine
6-Cylinder Diesel (180 hp)
Max Speed
120.0 km/h
Range
800.0 km
System
Alternative Designation
HMT 400 Supacat
Type
High Mobility Transporter (HMT)
Manufacturer
Supacat
Configuration
4x4
Crew
1 ea
Passenger Capacity
6 ea
Payload Capacity
2,100 kg
Dimensions
Length
5,790 mm
Width
2,050 mm
Height
Min 1885 mm | Max 2445 mm
Track
1700 mm
Wheelbase
3000 mm
Ground Clearance
Min 180 mm | Max 485 mm
Weight
7,600 kg
Automotive
Engine Name
Cummins 6.7L
Engine Type
6 cylinder Diesel
Engine Power
180 hp
Fuel Capacity
200 Litres
Maximum Speed
120 km/h
Maximum Road Range
800 km
Fording
1000 mm
Gradient
60%
Side Slope
35%
Drive
2WD/4WD, High low range
Brakes
Air over hydraulic system, ABS
Steering
Power assisted
Suspension
Independent with air adjustable ride height
Electrical System
24v DC
Options
Runflat tyres, locking differentials, self recovery winch, weapon mounts,
remote weapons station, smoke grenade launchers, IR lights, RHD or LHD.
Main Weapon System
Note
Supplied with an optional mine blast and ballistic
protection kit, the 400 can be fitted with a variety of
mission-specific hampers, weapons, communications, ISTAR
and force protection equipment to suit a wide range of
operational roles.
Protection
Armor
Supplied with an optional mine blast and ballistic
protection kit, the 400 can be fitted with a variety of
mission specific hampers, weapons, communications, ISTAR
and force protection equipment to suit a wide range of
operational roles.
Applique Armor
Available
Active Protection System
INA
Mine Clearing
No
Self-Entrenching Blade
No
NBC Protection
INA
Smoke Equipment
INA
Details
Country of Origin
United Kingdom
Category
Wheeled All-Terrain Vehicles
Land > All-Terrain Vehicles > Wheeled All-Terrain Vehicles
Filter Label
H
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
5.79 m
Width
2.05 m
Height
1.89 m
Weight
7600 kg
