EJDER YALÇIN Turkish 4x4 Tactical Wheeled Armored Vehicle
EJDER YALÇIN
Tactical Vehicle
Other
Basic Information
Name
EJDER YALÇIN Turkish 4x4 Tactical Wheeled Armored Vehicle
Designation
EJDER YALÇIN
Alternate Designation
EJDER YALÇIN
Equipment Type
Tactical Vehicle
Manufacturer
Nurol Makina
Date of Introduction
2014
Description
The EJDER YALÇIN Turkish 4x4 Tactical Wheeled Armored Vehicle is a modern Turkish tactical wheeled armored combat vehicle manufactured by Nurol Makina, representing one of the most successful light armored platforms in contemporary international markets. Designed to meet the protection and mobility requirements of military and security forces across diverse operational environments, the vehicle combines advanced survivability features with exceptional platform versatility. The EJDER YALÇIN features conventional layout architecture with engine forward, crew compartment amidships, and troop/cargo compartment aft. Configuration changes require minimal downtime, supporting rapid operational transitions. The EJDER YALÇIN 4x4 represents a balanced achievement of protection, mobility, and adaptability suited to contemporary asymmetric and conventional threat environments. With 300-horsepower engine output, STANAG 4569 Level 4a-3b mine protection, 110 km/h maximum speed, and 14 distinct operational configurations, the platform delivers tactical flexibility at lower cost and faster delivery than competing systems. Rapid export success—spanning Africa, Europe, Middle East, Central Asia, and Southeast Asia—demonstrates widespread acceptance among military decision-makers evaluating protected mobility platforms for diverse operational requirements.
Ground Specifications
Crew
2
Mobility Type
Wheeled (4x4)
Main Weapon
ASELSAN SARP (Stabilized Advanced Remote Weapon Platform) remote-controlled weapon station
Engine
6-Cylinder Turbocharged Diesel (300 hp)
NBC Protection
Yes
Max Speed
110.0 km/h
Range
600.0 km
Variants
Transport and Personnel
Personnel carrier (APC), armored ambulance.
Intelligence and Reconnaissance
Reconnaissance vehicle, border surveillance and security, CBRN surveillance.
Command and Control
Mobile command post, command and control vehicle.
Offensive Systems
Combat vehicle, anti-tank guided missile launcher, mortar carrier, tactical missile carriage/launch system.
Air Defense
Air defense vehicle, VSHORAD platform.
Specialist Operations
Mine/IED detection-clearance vehicle, radar platform, electronic warfare/jammer vehicle.
Extended Wheelbase Variant (EJDER YALÇIN EWB)
Nurol Makina unveiled an extended wheelbase variant at IDEX 2025, featuring increased internal volume and enhanced troop capacity while maintaining the platform's mobility and protection characteristics. The EWB variant provides superior accommodation for specialist equipment and larger personnel complements, with crossing capabilities including fording of up to 1.1 meters, trench crossing of 1.1 meters, and obstacle climbing of 0.5 meters, with 60 percent gradient resistance and 30 percent side slope capacity.
System
Alternative Designation
EJDER YALÇIN
Type
Tactical Wheeled Armored Vehicle
Manufacturer
Nurol Makina
Configuration
4x4
Crew
2 ea
Passengers
10 ea
Payload Capacity
4,000 kg
Dimensions
Length
5.42 m
Width
2.48 m
Height
2.30 m
Weight, Combat
12,000–14,000 kilograms (configuration dependent)
Wheelbase
3,100 mm
Automotive
Engine Name
Cummins
Engine Type
Turbocharged diesel 6-cylinder engine
Engine Power
300 horsepower at 2,100 rpm
Maximum Range
600 km
Maximum Speed
110 km/h
Amphibious
No
Gradient
70 percent
Side Slope
30 percent
Vertical Step
0.5 m
Trench
1.1 m
Fording
0.7 meters (without preparation, up to 1.1 meters with modifications)
Ground Clearance
400 mm
Turning Radius
7.5 m
Note
The platform utilizes permanent all-wheel drive with a double-wishbone fully independent suspension system for all wheels. Latitudinal and longitudinal differential locking systems, combined with large-diameter wide off-road tires, provide exceptional cross-country performance. The Central Tire Inflation System (CTIS) dynamically regulates pressure according to terrain conditions, and standard run-flat tire inserts enable continued mobility following puncture damage.
Main Weapon System
Weaponry and Firepower Integration
The EJDER YALÇIN supports modular integration of diverse weapon systems, enabling rapid reconfiguration for specific mission requirements. Standard configuration features two gun ports on the hull roof for manually-operated weapons.
Integrated Remote Weapon Stations
The primary fire control platform is the ASELSAN SARP (Stabilized Advanced Remote Weapon Platform) remote-controlled weapon station, which enables crew to engage targets while remaining under armor, significantly enhancing crew survivability. The SARP turret incorporates advanced features including fire-on-the-move capability, day/night imaging systems, automatic target tracking, and laser range finding for accurate ballistics.
Available Armament Options
7.62 millimeter machine gun; 2.7 millimeter (.50 caliber) machine gun; 25 millimeter anti-aircraft gun; 40 millimeter automatic grenade launcher; Anti-tank guided missile systems (Hellfire, Javelin, Kornet-E, Omtas, Shershen); Very-Short Range Air Defense (VSHORAD) systems (IGLA missile launcher); Mortar systems (Ragnarok 120mm from Rheinmetall); Indirect fire systems (Alkar from Aselsan); TRAKON 30mm remote weapon stations (EWB variant).
Protection
Ballistic Protection
The all-welded steel hull provides baseline protection against small arms fire and shell splinters, with optional modular add-on armor for enhanced ballistic defense. Transparent armor (bulletproof windows) features mesh protection, and optional cage armor offers protection against rocket-propelled grenades and shaped-charge threats.
Mine and IED Protection
The signature V-shaped hull design deflects upward-directed blast energy away from occupants during mine detonation or IED events. Floating floor plates and blast mitigation seating reduce injuries from blast overpressure and fragmentation effects. The vehicle demonstrates protection levels up to STANAG 4569 Level 4a-3b, providing comprehensive mine and ballistic protection
Applique Armor
Available
NBC Protection
Yes
Smoke Equipment
Yes
Image Sources
Details
Country of Origin
Turkey
Category
Mine-Resistant Ambush Protected (MRAP)
Land > Infantry Vehicles > Mine-Resistant Ambush Protected (MRAP)
Filter Label
E
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
5.42 m
Width
2.48 m
Height
2.3 m
Weight
12000 kg
Operators (12)
Turkey
Burkina Faso
Chad
Estonia
Georgia
Hungary
Malaysia
Morocco
Qatar
Senegal
Tunisia
Uzbekistan
