1V22 / MP-22 Slovakian Amphibious Air Defense Control Vehicle
1V22
Air-launched Cruise Missile (ALCM)
Other
Basic Information
Name
1V22 / MP-22 Slovakian Amphibious Air Defense Control Vehicle
Designation
1V22
Alternate Designation
1V22; MP-22; M1974-2B
Equipment Type
Air-launched Cruise Missile (ALCM)
Manufacturer
—
Date of Introduction
1974
Description
The 1V22 / MP-22 Slovakian Air Defense Control Vehicles is an air defense command and control vehicle. Typically, this vehicle is used by the command staff of 9K331 "Tor" (SA-15 air defense units. It carries a telescopic mast that is mounted on the front left of the hull. The vehicle can be recognized by the presence of this mast, and four roof antennas angled towards the rear of the vehicle. Also, the 1V25 / MP-25 vehicle featuring radar data processor subsystems typically works alongside the 1V22.
Ground Specifications
Crew
5
Mobility Type
Tracked
Main Weapon
1 x PKT 7.62mm General-Purpose Machine Gun
Engine
Diesel (240 hp)
NBC Protection
Yes
Max Speed
60.0 km/h
Variants
1V25 / MP-25
Features radar processing subsystem, additional C3 equipment to support SA-15 batteries.
System
Alternative Designation
1V22; MP-22; M1974-2B
Type
Air Defense Control Vehicle
Chassis
MT-LBu
Crew
5 ea
Dimensions
Height, Overall
2.72 m
Length, Chassis Overall
7.26 m
Width, Overall
2.85 m
Weight
INA
Automotive
Engine Name
YaMZ-238
Engine Type
Diesel
Engine Power
240 hp
Speed, Cross
INA
Speed, Maximum Road
60 km/h
Speed, Maximum Swim
4.5 km/h
Fording Depth
Amphibious
Sensors / Components
Fire Direction (Automated)
1V520
Fire Direction (Manual)
PUO-7
Navigation
1T121-M Navigation System
Other Equipment
1D15 laser rangefinder, DSP-30 rangefinder, 1PN44 day / night sight, PAB-2AM aiming circle, DS-1 stereoscopic rangefinder, VOP vision blocks and driver periscopes.
Radar Data Processor
T-235-1L
Main Weapon System
System
Name
1 x PKT 7.62mm General-Purpose Machine Gun
Type
General-Purpose Machine Gun
Caliber
7.62 mm
Range, Direct Fire
1,500 m
Range, Maximum Effective, Day
1,000 m
Range, Maximum Effective, Night
1,000 m
Rate of Fire, Cyclic
650 rd/min (2-10 round bursts)
Fire on Move
Yes
Sights
Iron Sights
Protection
Armor, Hull
15 mm
Armor, Turret Front
20 mm
NBC Protection
Yes
Smoke Equipment
No
Details
Country of Origin
Russia
Category
Land
Land
Filter Label
1
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.26 m
Width
2.85 m
Height
2.72 m
Weight
—
Operators (4)
Russia
Poland
Slovakia
CFE Treaty
