Piranha III 8x8

Piranha III 8x8

Wheeled Armored Vehicles
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Piranha III 8x8
Designation
Piranha III 8x8
Alternate Designation
Piranha IIIC 8x8
Equipment Type
Wheeled Armored Vehicles
Manufacturer
MOWAG GmbH
Date of Introduction
1997
Description

On October 5, 2004, Denmark placed a third order for Piranha IIIC 8x8 Armored Vehicles comprising 69 units valued at 140 million Swiss Francs ($112 million) including 22 additional vehicles ordered in 2003. In 1997, the Danish Army placed the first order for 22 Piranha IIIs with the second order for 22 additional vehicles placed in 2003. The third order strengthens Piranha III as the standard prime armored vehicle of Danish Armed Forces. Deliveries are scheduled to begin in February 2005. On 27 January 2006, the Irish Department of Defence signed a 30 million Euro contract with MOWAG GmbH for 15 Piranha III 8x8 armored vehicles. Nine of the combat vehicles were set to be equipped with Kongsberg 12.7mm stabilized and remotely controlled weapon station and the remaining six vehicles with an OTO-Melara 30mm gun. Piranha III deliveries were expected to start in February 2007. The Belgian government selected the Piranha IIIC 8x8 armored vehicle as a key element of its Army transformation into a lighter, more deployable, lethal, survivable and sustainable fighting force. This decision translated into a contract valued at 500 million Euro ($600 million) for a maximum of 242 vehicles and related logistics support. Under the terms of the Armored Infantry Vehicle (AIV) program the Belgian Army may receive 242 vehicles customized in seven variants: Infantry Carrier, Armored Personnel Carrier with Medium Caliber Gun, Direct Fire, Command Post, Engineering, Ambulance and Recovery. From 2007 to 2012 General Dynamics European Land Systems would deliver 138 vehicles with the additional vehicles delivered between 2012 and 2015.

Ground Specifications
Crew 2
Troop Capacity 12
Mobility Type Wheeled (8x8)
Main Weapon 105 millimeter (105mm)
Max Speed 100.1 km/h
Range 800.0 km
Overview (Deagel)
Group Wheeled Armored Vehicles
Status Active
Also Known As Piranha IIIC 8x8
Origin Switzerland
Contractor MOWAG GmbH
Initial Operational Capability (IOC) 1997
Total Production 1,389
Unitary Cost USD $1.2 million
Specifications (Deagel)
Crew 2
Troops 12
Wheel Drive 8
Wheels 8
Dimensions — Height 2.2 meter
Dimensions — Length 6.9 meter
Dimensions — Main Gun Caliber 105 millimeter
Dimensions — Width 2.7 meter
Mass — Combat Weight 18,500 kilogram
Mass — Empty Weight 12,500 kilogram
Mass — Payload 6,000 kilogram
Performance — Max Range 800 kilometer
Performance — Min Range 500 kilometer
Power — Power 400 shp
Speed — Top Speed 27.8 mps
Gear (Deagel)
Item 1 Vehicle Engines: 6V 183 TE22 (1)
Item 2 Weapon Stations: Protector
Variants
Variant 1 Piranha III 6x6
Variant 2 Piranha III 8x8
Variant 3 Piranha III 10x10
Variant 4 Piranha 3 CBRN
Variant 5 Piranha 3+
Details
Country of Origin Switzerland
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6.9 m
Width
2.7 m
Height
2.2 m
Weight
18500 kg
Operators (14)
United States
Sweden
Brazil
Spain
Belgium
Botswana
Denmark
Ireland
Moldova
New Zealand
Oman
Qatar
Romania
Switzerland
