FORCE 12x12

FORCE 12x12

Military Trucks
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
FORCE 12x12
Designation
FORCE 12x12
Alternate Designation
T 815-6MWR8T 39 324 (FORCE 10x10), T 815-6MWR8T 45 324 (FORCE 12x12), T 815-6ZVR8T 43 400 (FORCE 10x10)
Equipment Type
Military Trucks
Manufacturer
TATRA
Date of Introduction
Description

The TATRA FORCE, also known as T 815-6, is a modular vehicle family with great design flexibility and outstanding level of technical development making them suitable for operation in difficult muddy and sandy terrains. These trucks are designed to be used in the most difficult terrain and climate conditions in the areas where other vehicles are impossible to be operated. TATRA FORCE features nearly 100% use of water-cooled engines with power of over 300 kW, nearly 100% use of automatic transmissions, axles with wheel reduction gears and use of 16.00 R20 tactical tires. Their modular chassis configuration is available in 6x6, 8x8, 10x10 and 12x12 versions. TATRA FORCE vehicles belong to the category of the most heaviest military trucks with outstanding mobility in the most difficult terrain conditions. They are particularly suitable as a chassis for various special-purpose truck bodies such as a platform truck, hook container loaders, tanks, crush trucks and weapon system carriers. Moreover, FORCE trucks have proved to be perfect fire fighting vehicles because their powerful engines and automatic transmissions meet requirements on high acceleration and excellent mobility necessary to fight with wild fires in terrains inaccessible to other trucks.

Ground Specifications
Mobility Type Wheeled (12x12)
Max Speed 81.0 km/h
Range 500.0 km
Overview (Deagel)
Group Military Trucks
Status Active
Also Known As T 815-6MWR8T 39 324 (FORCE 10x10), T 815-6MWR8T 45 324 (FORCE 12x12), T 815-6ZVR8T 43 400 (FORCE 10x10)
Origin Czechia
Contractor TATRA
Total Production ?
Specifications (Deagel)
Wheel Drive 12
Wheels 12
Degree — Approach Angle 40 °
Degree — Departure Angle 35 °
Dimensions — Ground Clearance 390 millimeter
Dimensions — Height 3.2 meter
Dimensions — Length 14.0 meter
Dimensions — Track 2.1 meter
Dimensions — Width 2.5 meter
Energy — Max Torque 2,100 Nm
Mass — Cargo 33,560 kilogram
Mass — Max Weight 52,000 kilogram
Percentage — Gradient 85 %
Percentage — Side Slope 67 %
Performance — Ditch Crossing Ability 2 meter
Performance — Fording Depth 1.3 meter
Performance — Max Range 500 kilometer
Performance — Step Climbing Ability 0.60 meter
Performance — Turning Radius 17.1 meter
Power — Power 324 kW
Speed — Top Speed 81 kph
Volume — Fuel Tank Capacity 570 liter
Details
Country of Origin Czech Republic
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
14 m
Width
2.5 m
Height
3.2 m
Weight
52000 kg
Operators (2)
India
Czech Republic
