Mi-4 (Hound) Russian Transport Helicopter
Mil Mi-4
Utility Helicopter
Other
Basic Information
Name
Mi-4 (Hound) Russian Transport Helicopter
Designation
Mil Mi-4
Alternate Designation
Mil Mi-4; Type 36; NATO: Hound
Equipment Type
Utility Helicopter
Manufacturer
Mil
Date of Introduction
1953
Description
The Mil Mi-4 (USAF/DoD reporting name "Type 36", NATO reporting name "Hound") is a Soviet transport helicopter that served in both military and civilian roles. The Mi-4 was designed in response to the American H-19 Chickasaw and the deployment of U.S. helicopters during the Korean War. While the Mi-4 strongly resembles the H-19 Chickasaw in general layout, including the innovative engine position in front of the cockpit, it is a larger helicopter, able to lift more weight and built-in larger numbers. The first model entered service in 1953. The helicopter was first displayed to the outside world in 1952 at the Soviet Aviation Day in Tushino Airfield. One Mi-4 was built with a jettisonable rotor. It served as an experimental vehicle for future pilots' means of safety and ejection designs
Air & Air Defense Specifications
Crew
1
Engine
14-cylinder air-cooled radial piston engine (1680 hp)
Max Speed
185.0 km/h
Range
500.0 km
Service Ceiling
5500 m
Variants
Variants
V-12
Prototype. Designation reused for the Mi-12.
Mi-4 (NATO – Hound-A)
Basic production version.
Mi-4A
Assault transport helicopter.
Mi-4AV
Armed versions based on the Mi-4A. V for Vooruzhenniy (Armed). Mi-4A with additional armament. Modification of 1967 had weapons complex K-4V, included four 9М17М ATGM "Phalanga" and 96 57-mm NAR S-5M in six blocks UB-16-57U (or six 100-kg bombs or four 250-kg bombs or tanks with an incendiary substance); 185 helicopters were converted to Mi-4AV.
Mi-4GF
Factory designation for demilitarised Mi-4 for use in the Civil Air Fleet.
Mi-4L Lyukes
Six-seat VIP transport version, sometimes converted into an air ambulance helicopter.
Mi-4VL
Fire-fighting version of Mi-4L.
Mi-4M (NATO – Hound-C)
Anti-submarine warfare helicopter with searching radar station SPRS-1 ("Kurs-M"), hydroacoustic station "Baku", additional fuel tank and rescue boat with operator in under-fuselage gun turret.
Mi-4ME
Export modification of Mi-4M.
Mi-4VM
Slightly modified version of Mi-4M, differed by some avionics system.
Mi-4MR
Upgraded version of Mi-4VM with the searching radar station "Rubin-V" instead of "Kurs-M".
Mi-4P / Mi-4VP
Civil transport helicopter, with accommodation for between 8 and 11 passengers, plus eight stretchers and a medical attendant for air ambulance duties.
Mi-4PL (NATO – Hound-B)
Anti-submarine warfare helicopter.
Mi-4PS
SAR version.
Mi-4S Salon
VIP transport helicopter.
Mi-4Skh
Multi-role agricultural helicopter, with a large chemical container in the main cabin. Also used as a fire-fighting helicopter.
Mi-4T
Major military production version, equipped with a large diameter main rotor and bulged windows.
Mi-4VM (VM-12)
Anti-submarine warfare helicopter.
Mi-4BT
Minesweeper with floats.
Mi-4RI
Mi-4M equipped with the Rion experimental sonar.
Mi-4MT
Torpedo-carrying ASW attack (killer) aircraft derived from Mi-4M.
Mi-4MU
Attack helicopter.
Mi-4MO
Search helicopter with Oka sonar.
Mi-4MS
Search helicopter with Soora infra-red sensor.
Mi-4FV (Mi-4KV)
Photographic and guidance helicopter.
Mi-4Schch
"Polar version" of Mi-4FV for working at the Soviet Arctic and Antarctic research stations.
Mi-4SP
Special rescue modification.
Mi-4PG
Experimental version equipped with an external load sling system.
Mi-4SV
Mi-4 with improved heat insulation for working in the Far North.
Mi-4N "Filin" (Horned owl)
Experimental reconnaissance version intended for night-time use.
Mi-4KK (Mi-4VKP)
Mobile command post.
Mi-4KU (Mi-4VPU)
Mobile command post for controlling Air Force units.
Mi-4U
Target-designator version carrying the Oospekh (Success) system.
Mi-4GR
Mi-4 fitted with Grebeshok-3 (Haircomb-3) wide-range panoramic detection and relay radar.
Mi-4TARK
TV-equipped artillery reconnaissance and spotting helicopter.
Mi-4MK (Mi-4PP)
ECM version.
Mi-4UM
Radio-controlled target drone version.
Harbin Z-5
Chinese military transport helicopter. Chinese production version.
Harbin Z-6
Prototype turbine powered version of the Z-5, no production undertaken.
Xuanfeng
Chinese civil transport helicopter. Chinese production version.
System
Alternative Designation
Mil Mi-4; Type 36; NATO: Hound
Type
Transport Helicopter
Manufacturer
Mil Moscow Helicopter Plant
Crew
1 or 2 ea
Passengers
16 troops
Blades, Main Rotor
4 ea
Blades, Tail Rotor
3 ea
Number of Engines
1 ea
Number of Hard Points
INA
Dimensions
Length
16.8 m
Width
INA
Height
4.4 m
Main Rotor Diameter
21 m
Main Rotor Area
346.4 m2
Cargo Capacity
1,600 kg of cargo
Weight, Empty
5,100 kg
Weight, Gross
7,150 kg
Automotive
Engine Name
1 × Shvetsov ASh-82V
Engine Type
14-cylinder air-cooled radial piston engine
Engine Power
1,680 hp
Maximum Speed
185 km/h
Range
500 km
Service Ceiling
5,500 m
Disk Loading
41 kg/m2
Fire Control and Avionics
Fire Control System Type
INA
Fire Control Radar
INA
Navigation Radar
INA
Laser Designator
INA
Protection
Stealth Properties
None
Add on Armor
INA
Heat Signature Reduction
INA
NBC Protection
INA
EW Counter Measures/CCM
INA
Counter Measures (Chaff/Flares)
INA
Details
Country of Origin
Russia
Category
Transport Helicopter
Air > Transport Helicopter
Filter Label
M
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
16.8 m
Width
—
Height
4.4 m
Weight
7150 kg
Operators (26)
Russia
Poland
India
North Korea
Soviet Union
Afghanistan
Albania
Algeria
Bangladesh
Bulgaria
Cambodia
Cuba
Egypt
Finland
Hungary
Indonesia
Iraq
Laos
Mali
Mongolia
Romania
Somalia
Sudan
Syria
Vietnam
Yemen
