Goryn-Class (Project 714 Class) Russian Ocean Salvage Tug
Goryn-Class
Ocean Salvage Tug
Other
Basic Information
Name
Goryn-Class (Project 714 Class) Russian Ocean Salvage Tug
Designation
Goryn-Class
Alternate Designation
Goryn-Class; Project 714 Class
Equipment Type
Ocean Salvage Tug
Manufacturer
—
Date of Introduction
1982
Description
The Goryn-Class (Project 714 Class) Russian Ocean Tugs are officially designated as SB for rescue tugs or MB for oceangoing salvage ships. The SB ships can be distinguished from their fleet tug sister ships by electrohydraulic crane and small tripod mast abaft the stack.
Naval & Littoral Specifications
Crew
43
Beam
14.05 m
Draft
5.50 m
Variants
MB-29
Commissioned: 1821
Status: Active
Fleet: Northern Fleet
MB-32
Commissioned: 1982
Status: Decommissioned in 2015
Fleet: Pacific Fleet
MB-35
Commissioned: 1982
Status: Active
Fleet: Baltic Sea Fleet
MB-36
Commissioned: 1982
Status: Active
Fleet: Black Sea Fleet
MB-38
Commissioned: 1982
Status: Decommissioned in 2018
Fleet: Northern Fleet
MB-61
Commissioned: 1983
Status: Active
Fleet: Pacific Fleet
MB-62
Commissioned: 1983
Status: Active
Fleet: Pacific Fleet
MB-64
Commissioned: 1983
Status: Active
Fleet: Northern Fleet
MB-108
Commissioned: 1983
Status: Active
Fleet: Black Sea Fleet
Kremenets U705 (Ukraine)
Commissioned: INA
Status: Active
Fleet: Ukraine Fleet
System
Alternative Designation
Goryn-Class; Project 714 Class
Type
Russian Ocean Tug
Builder
Rauma-Repola, Rauma, Finland
Crew
43 total (civilians)
Diving Complex
1 x Diving Complex and 1 x 40 meter Pressure Chamber
Dimensions
Length
63.50 m
Beam
14.05 m
Draft
5.50 m
Displacement, Standard
1,435 tons
Displacement, Full Load
2,210 tons
Communications
Note
The MB savage ships have probably been fitted with MG-26 underwater telephones.
Propulsion System
Engine Name
1 x Russkiy Type 67N
Engine Type
Diesel
Engine Power
7,000 total bhp
Bow Thruster
1 x Bow Thruster
Generators
1 x 132 kW diesel-generator
Maximum Range
8000 nmi at 12 knots
Maximum Speed
14 knots
Endurance
30 days
Gun Weapon Systems
Note
There are no weapons mounted onboard the Goryn-Class (Project 714 Class) Russian Ocean Tug.
Radar Systems
Navigation Radars
2 x Don Navigation Radars
Protection
Hull
INA
Countermeasures
No
NBC Water Washdown System
Yes
Details
Country of Origin
Russia
Category
Support Ships
Naval > Support Ships
Filter Label
G
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
63.5 m
Width
—
Height
—
Weight
—
Operators (2)
Russia
Ukraine
