MC-130W Combat Spear

MC-130W Combat Spear

Military Transport Aircrafts
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
MC-130W Combat Spear
Designation
MC-130W Combat Spear
Alternate Designation
C-130W Dragon Spear
Equipment Type
Military Transport Aircrafts
Manufacturer
Lockheed Martin
Date of Introduction
2006
Description

MC-130W is a modified C-130H aircraft intended to support US Air Force Special Operations Command (AFSOC) replacing MC-130Hs and MC-130Ps lost performing missions during the global war on terrorism. The first MC-130W aircraft was rolled out on 28 June 2006 at Robins Air Force Base, Georgia. A dozen such modified aircraft were required by the US Air Force to replace four MC-130Hs and one MC-130P combat losses logged until June 2006. The new Combat Talon variant is based on C-130H airframes from 1987 to 1990. MC-130W leverages the same abilities of its predecessors, mainly infiltration and exfiltration, but adding air-to-air refueling in support of special operations and search and rescue (SAR) helicopters. Air refueling pods were added to this Combat Talon variant for that purpose. MC-130W can be refueled in-flight to extend its mission range. Modifications also include a basic electronic warfare capability to avoid potential threats, ability to work in special light conditions and strengthening of the tail.

Overview (Deagel)
Group Military Transport Aircrafts
Status Active
Also Known As C-130W Dragon Spear
Origin United States of America
Contractor Lockheed Martin
Initial Operational Capability (IOC) 2006
Total Production 12
Specifications (Deagel)
Number of Engines 4
Dimensions — Height 7 meter
Dimensions — Length 30.4 meter
Power — Max Power at TakeOff 19,640 shp
Gear (Deagel)
Item 1 Anti-Tank Guided Missiles: Griffin A
Item 2 Medium Caliber Cannons: GAU-23
Item 3 Turboprop Engines: T56-A-16 (4)
Variants
Variant 1 C-130H Hercules
Variant 2 MC-130H Talon II
Variant 3 AC-130U Spooky
Variant 4 C-130J Super Hercules
Variant 5 CC-130J Super Hercules
Variant 6 KC-130J Super Hercules
Variant 7 WC-130J
Variant 8 MC-130W Combat Spear
Variant 9 EC-130J Commando Solo
Variant 10 MC-130J Commando II
Variant 11 AC-130J Ghostrider
Variant 12 LM-100J
Variant 13 C-130J-SOF
Details
Country of Origin United States
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
30.4 m
Width
Height
7 m
Weight
Operators (1)
United States
