9K333 Verba (SA-29) Russian Man-Portable Infrared Homing Surface-to-Air Missile (MANPAD)

9K333 Verba (SA-29)

Man-Portable Air Defense System (MANPADS)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
9K333 Verba (SA-29) Russian Man-Portable Infrared Homing Surface-to-Air Missile (MANPAD)
Designation
9K333 Verba (SA-29)
Alternate Designation
9K333 Verba (SA-29)
Equipment Type
Man-Portable Air Defense System (MANPADS)
Manufacturer
KB Mashinostroyeniya - developer of the system
Date of Introduction
2014
Description

The 9K333 Verba (SA-29) Russian Man-Portable Infrared Homing Surface-to-Air Missile (MANPAD) was developed by the Russian Konstruktorskoye Byuro Mashinostroyenia (KBM). It was unveiled in 2015. It was developed as a replacement for the 9K38 Igla system, which is currently used by Russian forces. Igla system is being used by many countries worldwide. The new Verba system uses a surface-to-air missile to engage air targets. It was approved for production in 2011 and adopted by the Russian Armed Forces in 2014. It is also being proposed for export customers. Verba's kill range is similar to the Igla-S (6 Km) and operating altitude is about 4.5 Km. But the engagement envelope has been extended by a factor of 2.5 besides improved protection from countermeasures. The general performance factor has been increased by 1.5 to 2.

Air & Air Defense Specifications
Crew 1
Range 6.0 km
System
Alternative Designation 9K333 Verba (SA-29)
Type Man-Portable Infrared Homing Surface-to-Air Missile
Family 9K333
Manufacturer KB Mashinostroyeniya - developer of the system
In Service 2014-Present
Crew 1 ea
Dimensions
Note See Missile System
Missile System
System
Name 9K333 Verba (SA-29)
Type Man-Portable Air Defense System (MANPADS)
Missile Length 1.64 m
Missile Diameter 0.07 m
Fin Span INA
Missile Weight 12 kg
Launcher Type 9P521 launcher
Launcher Weight 6 kg
Missile Weight with Launcher 18 kg
Engine Solid fuel rocket motor
Warhead Type High Explosive Blast Fragmentation
Warhead Weight 1.5 kg
Range of Fire 6 km
Flight Ceiling 4.5 km
Guidance System Three-channel optical seeker (ultraviolet, near-infrared, mid-infrared)
Fire Control
Name INA
Computerized FCS The new MANPADS also includes integrated automated control system. This enables data usage from both ground and early radar warning aircraft. Thus targets can be traced in advance and passed to MANPAD operators for engagement.
Direct Fire Yes
Imaging Sight Maugli-2M infrared imaging sight
Identification Friend-or-Foe (IFF) Interrogator Yes
Details
Country of Origin Russia
Category Man-Portable Air-Defense Systems (MANPADS)
Land > Air Defense > Man-Portable Air-Defense Systems (MANPADS)
Filter Label
9
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
1.64 m
Width
0.07 m
Height
Weight
18 kg
Operators (3)
Russia
Armenia
Syria
